• for PR number: 1KE
• Fitting Position: Rear Axle
• Brake System: Lucas
• Height [mm]: 59
• Width [mm]: 117
• Thickness [mm]: 17.7
• Wear Warning Contact: excl. wear warning contact

Lisainfo: Brake pad set, rear, 17.7 mm, without wear indicator Additional information: Brake pad set, rear, 17.7 mm, without wear indicator

• Fitting Position: Rear Axle
• General Information: Brake pad; rear; without wire
• Manufacturer: VIKA

• for PR number: 1KE
• Fitting Position: Rear Axle
• Height [mm]: 59
• Thickness [mm]: 17.7
• Wear Warning Contact: excl. wear warning contact
• Brake System: Lucas
• Width [mm]: 116
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MAX

• for brake disc diameter [mm]: 300
• for PR number: 1KE
• Length [mm]: 116.2
• Width [mm]: 58.6
• Test Mark: ECE R90 Approved
• Fitting Position: Rear Axle
• Thickness 1 [mm]: 17.5
• Wear Warning Contact: prepared for wear warning indicator
• Weight [kg]: 1.4
• Observe service information:
• Manufacturer: FEBI HAMULCE

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle
• Wear Warning Contact: prepared for wear warning indicator
• Height 1 [mm]: 59
• Brake System: LUCAS/TRW
• Width 1 [mm]: 116
• Thickness 1 [mm]: 17
• Manufacturer: PROFIPOWER

• Fitting Position: Front Axle
• for PR number: 1LJ
• Brake System: ATE
• Width 1 [mm]: 72.9
• Width 2 [mm]: 72.9
• Thickness [mm]: 20.3
• Warning Contact Length [mm]: 243
• Test Mark: ECE R90
• Height 1 [mm]: 155.1
• Height 2 [mm]: 156.3
• Assy./disassy. by qualified personnel required!:
• Manufacturer: ABAKUS LORO

General Information: The following information is for general and informational purposes only and does not constitute warranty terms. Warranty terms and conditions are available from our dealers and in our general terms and conditions of sale. Abakus spare/repair parts are intended only for vehicle repairs in order to restore their original functionality. Abakus spare/repair parts are used or sold to users only for the purpose of repairing vehicles to restore their original look and functionality and are not original/genuine/OE/OEM/OES replacement parts. These items do not originate from the vehicle manufacturer and may be the subject of a design not owned by Abakus and the manufacturer of this spare part. They may only be used for repairs to restore the intended vehicle to its original appearance. Our products are delivered without instruction of installation. Installation of our product may only be carried out by trained specialist technicians in specific car repairs. Products supplied by us are exclusively intended for proper and appropriate use. The warranty may become invalid in the event of: improper installation or repair, unsuitable application or use, installation or repair made outside specialist car workshops. Warranty claims are lost if the vehicle is modified and used for motor sports, tuning or similar events (except our tuning parts which are described in TecDoc and on our price list). Warranty application should include complete documentation among others: chassis no., first registration, vehicle mileage, information about LPG installation, fault memory log, pictures, our QC (quality check) code, installation invoice, contact details of the car repair workshop performing the replacement or repair. Warranty application are available in our Client Panel system. Complaints may require supplementing data such as error memory logs. Incomplete documentation may result in rejection of the claim. Any damage caused during transport is not considered quality damage and will be considered on an individual basis. The product is intended for use within the performance limits specified by the manufacturer and should only be used by qualified personnel who have been trained to operate this product. Before each use, the product should be checked for damage or fixing of its parts and not used if any defects or loose parts are found. Failure to follow the manufacturer's guidelines could result in potential product damage or even injury. Wear appropriate protective clothing if necessary when working with the product.

• for brake disc diameter [mm]: 300
• for PR number: 1KE
• Length [mm]: 116.2
• Width [mm]: 58.6
• Test Mark: ECE R90 Approved
• Fitting Position: Rear Axle
• Thickness 1 [mm]: 17.5
• Weight [kg]: 1.4
• Name: SW 30 91 6588
• Manufacturer: SWAG

Wear Warning Contact: excl. wear warning contact, prepared for wear warning indicator General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle
• Brake System: TRW
• Width [mm]: 116
• Height [mm]: 59
• Thickness [mm]: 17.4
• WVA Number: 23326
• Wear Warning Contact: excl. wear warning contact
• Supplementary Article/Info 2: with anti-squeak plate
• Test Mark: ECE-R90
• Weight [kg]: 1.48
• Manufacturer: VALEO
• Name: VA 301004

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• Width [mm]: 117
• Thickness [mm]: 18
• Height [mm]: 59
• Wear Warning Contact: excl. wear warning contact
• Supplementary Article/Supplementary Info: with accessories
• Brake System: Lucas
• Supplementary Article/Info 2: with brake caliper screws, with anti-squeak plate
• WVA Number: 23326
• Name: BR P 85 076
• Manufacturer: BREMBO

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• Width [mm]: 116.1
• Thickness [mm]: 17.5
• Brake System: TRW
• Height [mm]: 58.9
• Supplementary Article/Info 2: with bolts/screws
• Manufacturer: LPR

• for brake disc diameter [mm]: 300
• for PR number: 1KE
• Thickness [mm]: 17.5
• Length [mm]: 116
• Height 1 [mm]: 59
• Brake System: TRW
• WVA Number: 23326
• Fitting Position: Rear Axle
• Manufacturer: JAPKO

• for brake disc diameter [mm]: 300
• for PR number: 1KE
• Thickness [mm]: 17.5
• Length [mm]: 116
• Height 1 [mm]: 59
• Brake System: TRW
• WVA Number: 23326
• Fitting Position: Rear Axle
• Manufacturer: ASHIKA-KLOCKI

• Fitting Position: Front Axle
• Width [mm]: 73
• Thickness [mm]: 20
• Number of wear indicators [per axle]: 2
• Wear Warning Contact: incl. wear warning contact
• Brake System: ATE
• Warning Contact Length [mm]: 240
• Height 1 [mm]: 155
• Height 2 [mm]: 156
• Manufacturer: KAMOKA UK£ADY HAMULCOWE

• Fitting Position: Rear Axle
• Width [mm]: 116.1
• Height [mm]: 58.7
• Thickness [mm]: 17.3
• Wear Warning Contact: excl. wear warning contact
• Brake System: TRW
• Supplementary Article/Info 2: with anti-squeak plate
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MEY
• Lisainfo: 0252332617
• Additional information: 0252332617

• for OE number: 7H0 698 451
• Fitting Position: Rear Axle
• Manufacturer: TRUCKTEC
• Additional information: 07.35.239 TRUCKTEC
• Lisainfo: 07.35.239 TRUCKTEC

• Fitting Position: Rear Axle
• Brake System: Trw
• Quantity per packing unit: 4
• Test Mark: ECE-R90
• Height 1 [mm]: 58.6
• Wear Warning Contact: prepared for wear warning indicator
• Vibration: with vibration damper
• Width 1 [mm]: 116.2
• Thickness 1 [mm]: 17.5
• Manufacturer: METELLI UKL.HAMULCOWY

• for PR number: 1KE
• Quantity per packing unit: 4
• Fitting Position: Rear Axle
• Thickness [mm]: 17.5
• Width [mm]: 116.2
• Height [mm]: 59
• Braking System: only in conjunction with steel brake discs
• Brake System: TRW
• Weight [kg]: 1.25
• Manufacturer: TOMEX C

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Thickness [mm]: 20.2
• Height [mm]: 72.8
• Number of wear indicators [per axle]: 2
• Brake System: ATE
• Warning Contact Length [mm]: 240
• Width 1 [mm]: 155
• Width 2 [mm]: 156
• Manufacturer: LPR

• Fitting Position: Rear Axle
• for PR number: 1KE
• Width 1 [mm]: 116
• Height 1 [mm]: 59
• Thickness 1 [mm]: 17
• Brake System: LUCAS/TRW
• Warning Contact Length [mm]: 260
• Wear Warning Contact: prepared for wear warning indicator
• Weight [kg]: 1.4
• Installation Information: Important: Observe Fitting Instructions
• Manufacturer: ABS

• for brake disc diameter [mm]: 345
• for PR number: 1LJ
• Thickness [mm]: 20.2
• Test Mark: R90 Homologated
• Length [mm]: 155
• Weight [kg]: 2.7
• Height 1 [mm]: 72.8
• Wear Warning Contact: incl. wear warning contact
• Supplementary Article/Supplementary Info: without accessories
• Brake System: ATE
• Length 1 [mm]: 156
• Supplementary Article/Info 2: with piston clip
• Fitting Position: Front Axle
• WVA Number: 23801, 23950
• Manufacturer: ASHIKA-KLOCKI

• for PR number: 1LJ
• Fitting Position: Front Axle
• Thickness [mm]: 20.3
• Wear Warning Contact: incl. wear warning contact
• Brake System: ATE
• Width 1 [mm]: 72.9
• Width 2 [mm]: 72.9
• Height 1 [mm]: 155.1
• Height 2 [mm]: 156.3
• Manufacturer: DENCKERMANN ZAWIESZENIE

• Fitting Position: Front Axle
• Wear Warning Contact: with integrated wear sensor
• Number of wear indicators [per axle]: 2
• Height 1 [mm]: 73
• Height 2 [mm]: 73
• Brake System: ATE
• Warning Contact Length [mm]: 250
• Width 1 [mm]: 155.3
• Width 2 [mm]: 156.3
• Thickness 1 [mm]: 20
• Thickness 2 [mm]: 20
• Manufacturer: JPN

• Fitting Position: Rear Axle
• for PR number: 1KE
• Thickness [mm]: 16.9
• Length [mm]: 116.1
• Height [mm]: 58.9
• Wear Warning Contact: not prepared for wear warning indicator
• Brake System: Trw
• Manufacturer: DRIVE

Braking System: only in conjunction with steel brake discs, not for carbon-ceramic brake discs

• Quantity per packing unit: 4
• Fitting Position: Rear Axle
• Thickness [mm]: 17.4
• Width [mm]: 116
• Height [mm]: 58.9
• Brake System: Lucas - Girling
• Supplementary Article/Info 2: with brake caliper screws
• Manufacturer: OPTIMAL ZAWIESZENIE

Wear Warning Contact: prepared for wear warning indicator, excl. wear warning contact

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Manufacturer Restriction: ATE
• Length 1 [mm]: 155.2
• Length 2 [mm]: 156.4
• Height [mm]: 72.9
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Observe technical data:
• Manufacturer: AUTO-GH

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs

• Fitting Position: Front Axle
• Thickness [mm]: 20
• Height [mm]: 72.9
• Manufacturer Restriction: ATE
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Observe technical data:
• Width 1 [mm]: 156
• Width 2 [mm]: 155
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MAX

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• FMSI Code: D1018-7821
• Test Mark: E4 90R-01465/1691
• Brake System: TRW
• Supplementary Article/Info 2: with anti-squeak plate
• Supplementary Article/Supplementary Info: with accessories
• WVA Number: 23326
• Friction Lining Material: Low-Metallic
• Wear Warning Contact: not prepared for wear warning indicator
• Width 1 [mm]: 116.4
• Width 2 [mm]: 116
• Height 1 [mm]: 59
• Height 2 [mm]: 59
• Thickness 1 [mm]: 17.5
• Thickness 2 [mm]: 17.5
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE LP1920

• Fitting Position: Front Axle
• Manufacturer Restriction: ATE
• Height [mm]: 72.9
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Braking System: only in conjunction with steel brake discs
• Width [mm]: 156
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MAX

• Fitting Position: Rear Axle
• Quantity per packing unit: 4
• Brake System: LUCAS-GIRLING
• Width [mm]: 87
• Height [mm]: 53
• Thickness [mm]: 17
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Supplementary Article/Info 2: with bolts/screws
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Fitting Position: Rear Axle
• Quantity per packing unit: 4
• Brake System: LUCAS-GIRLING
• Width [mm]: 87
• Height [mm]: 53
• Thickness [mm]: 17
• Wear Warning Contact: prepared for wear warning indicator
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Supplementary Article/Info 2: with bolts/screws
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Quantity: 1
• Fitting Position: Front Axle
• Width [mm]: 117.2
• Thickness [mm]: 19.5
• Height [mm]: 69.7
• Material: Low-Metallic
• Wear Warning Contact: incl. wear warning contact
• Supplementary Article/Info 2: with mounting manual
• General Information: Brake pad; front; with wire
• Manufacturer: VIKA

• Fitting Position: Front Axle
• Brake System: CONTINENTAL
• Width [mm]: 157
• Height [mm]: 73
• Thickness [mm]: 20
• WVA Number: 23801
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Operating Mode: Electric
• Supplementary Article/Info 2: with anti-squeak plate
• Test Mark: ECE-R90
• Weight [kg]: 2.12
• Name: VA 302440
• Manufacturer: VALEO

• Fitting Position: Rear Axle
• Width [mm]: 116.1
• Height [mm]: 58.7
• Thickness [mm]: 17.3
• Wear Warning Contact: prepared for wear warning indicator
• Brake System: TRW
• Supplementary Article/Info 2: with brake caliper screws, with anti-squeak plate
• Quality: PREMIUM
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MEY

General Information: Different chamfers on the leading and trailing edges of the brake pads support the silent performance of MEYLE-PD. To ensure this silent performance, slotting and chamfer are individually designed for each brake pad.

• Fitting Position: Front Axle
• for brake disc diameter [mm]: 288, 312
• for PR number: 1LB, 1LE, 1LF, 1LT
• Quantity per packing unit: 4
• Number of pads: 4
• Length [mm]: 156.4
• Height [mm]: 74.5
• Height 2 [mm]: 74.5
• Wear Warning Contact: incl. wear warning contact
• Brake System: ATE
• Warning Contact Length [mm]: 196
• Thickness 1 [mm]: 19.3
• Thickness 2 [mm]: 20.2
• WVA Number: 20676, 23018, 23019
• Name: SK VKBP80113E
• Manufacturer: SKF

• Fitting Position: Rear Axle
• Quantity per packing unit: 4
• Number of pads: 4
• Thickness [mm]: 17
• Length [mm]: 116
• Height [mm]: 58.5
• Wear Warning Contact: not prepared for wear warning indicator
• Brake Lining: With bevelled edges
• Brake System: TRW
• WVA Number: 23326
• Name: SK VKBP90221
• Manufacturer: SKF

• Fitting Position: Front Axle
• for brake disc diameter [mm]: 280
• for PR number: 1LZ
• Quantity per packing unit: 4
• Number of pads: 4
• Thickness [mm]: 19.3
• Length [mm]: 118.8
• Height [mm]: 69.5
• Wear Warning Contact: incl. wear warning contact
• Brake Lining: With bevelled edges
• Brake System: TRW
• WVA Number: 21945, 23393
• Name: SK VKBP80547E
• Manufacturer: SKF

• Fitting Position: Front Axle
• Brake System: ATE
• WVA Number: 23018
• Length 1 [mm]: 156.4
• Height 1 [mm]: 74.2
• Thickness 1 [mm]: 19.5
• Thickness 2 [mm]: 19
• Wear Warning Contact: with integrated wear sensor
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 200
• Manufacturer: MAGNETI MARELLI

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• Manufacturer Restriction: TRW
• Width [mm]: 116.2
• Height [mm]: 59
• Thickness [mm]: 17.5
• Wear Warning Contact: not prepared for wear warning indicator
• Supplementary Article/Info 2: with brake caliper screws
• Supplementary Article/Supplementary Info: with accessories
• Test Mark: E9 90R - 01120/613
• Observe technical data:
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: TRW
• Quality class: Q

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs SVHC: No information available, please contact the manufacturer!

• Engine Code: BBK
• Fitting Position: Rear Axle
• for PR number: 1KE
• Supplementary Article/Supplementary Info: with accessories
• Supplementary Article/Info 2: with bolts/screws
• Article number of recommended accessories: 1987474314, 1987474419, 1987474402, 1987474328
• Product must be determined on the vehicle or the motor:
• Material: Low-Metallic
• Test Mark: ECE-R90
• WVA Number: 23326
• Thickness [mm]: 17.5
• Width [mm]: 116.2
• Height [mm]: 58.6
• Number of bolts/screws: 2
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: BOS

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• Brake System: LUCAS-GIRLING
• Width [mm]: 116
• Height [mm]: 59
• Thickness [mm]: 18
• Wear Warning Contact: prepared for wear warning indicator
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• for PR number: 1LJ
• Width 1 [mm]: 156
• Height [mm]: 72
• Thickness [mm]: 20
• Wear Warning Contact: with integrated wear sensor
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Brake System: Teves
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: QUARO

• for PR number: 1LJ
• Quantity per packing unit: 4
• Fitting Position: Front Axle
• Thickness [mm]: 20
• Height [mm]: 72.9
• Number of wear indicators [per axle]: 2
• Wear Warning Contact: incl. wear warning contact
• Brake System: ATE
• Warning Contact Length [mm]: 225
• Width 1 [mm]: 156.4
• Width 2 [mm]: 155.2
• Weight [kg]: 2.4
• Manufacturer: TOMEX C

• Fitting Position: Rear Axle
• for PR number: 1KE
• Quantity per packing unit: 4
• Width [mm]: 116.5
• Height [mm]: 59
• Thickness [mm]: 17.7
• Wear Warning Contact: not prepared for wear warning indicator
• Supplementary Article/Info 2: with brake caliper screws
• Supplementary Article/Supplementary Info: with accessories
• WVA Number: 23326
• Brake System: Lucas
• Weight [kg]: 1.381
• Assy./disassy. by qualified personnel required!:
• Name: HE 8DB355010971
• Manufacturer: HELLA PAGID

• Fitting Position: Front Axle
• Construction Year from: 07.2003
• Quantity per packing unit: 4
• FMSI Code: D915-7796
• Test Mark: E9 90R-01823/1237
• Brake System: Continental
• Supplementary Article/Info 2: with anti-squeak plate
• Supplementary Article/Supplementary Info: without accessories
• WVA Number: 23950, 23801
• Friction Lining Material: Low-Metallic
• Wear Warning Contact: incl. wear warning contact
• Width 1 [mm]: 155.6
• Width 2 [mm]: 156.4
• Height 1 [mm]: 72.9
• Height 2 [mm]: 72.9
• Thickness 1 [mm]: 20.3
• Thickness 2 [mm]: 20.3
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE LP1922
• Quality class: PJ

• for brake disc diameter [mm]: 345
• for PR number: 1LJ
• Length [mm]: 156.4, 155.2
• Width [mm]: 72.9
• Test Mark: ECE R90 Approved
• Supplementary Article/Info 2: with piston clip
• Fitting Position: Front Axle
• Thickness 1 [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Weight [kg]: 2.24
• Observe service information:
• Manufacturer: FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle
• for PR number: 1KE
• Width [mm]: 116.5
• Height [mm]: 59
• Thickness [mm]: 17.7
• Wear Warning Contact: not prepared for wear warning indicator
• Supplementary Article/Info 2: with brake caliper screws
• Supplementary Article/Supplementary Info: with accessories
• WVA Number: 23326
• Brake System: Lucas
• Packaging length [cm]: 15.2
• Packaging width [cm]: 8.8
• Packaging height [cm]: 8.4
• Weight [kg]: 1.381
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: TEX

• for PR number: 1LA
• Fitting Position: Front Axle
• Width 1 [mm]: 155.1
• Width 2 [mm]: 156.4
• Height [mm]: 72.8
• Thickness [mm]: 20
• Number of wear indicators [per axle]: 2
• Wear Warning Contact: incl. wear warning contact
• Warning Contact Length [mm]: 242.5
• Brake System: ATE
• Supplementary Article/Info 2: with anti-squeak plate
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MEY

• Fitting Position: Front Axle
• Quantity per packing unit: 4
• Number of pads: 4
• Thickness [mm]: 19.5
• Height [mm]: 72.8
• Wear Warning Contact: incl. wear warning contact
• Brake Lining: With bevelled edges
• Brake System: Teves
• Length 1 [mm]: 155.2
• Length 2 [mm]: 156.3
• WVA Number: 23762, 23763, 23801
• Name: SK VKBP80617E
• Manufacturer: SKF

• Brake System: Ate
• Fitting Position: Front Axle
• Quantity per packing unit: 4
• Test Mark: ECE-R90
• Height 1 [mm]: 72.9
• Height 2 [mm]: 72.9
• Wear Warning Contact: incl. wear warning contact
• Vibration: with vibration damper
• Width 1 [mm]: 156.3
• Width 2 [mm]: 155.1
• Thickness 1 [mm]: 20
• Manufacturer: METELLI UKL.HAMULCOWY

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Manufacturer Restriction: ATE
• Length 1 [mm]: 155.2
• Length 2 [mm]: 156.4
• Height [mm]: 72.9
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Warning Contact Length [mm]: 270
• directional:
• Test Mark: E9 90R - 01107/708
• Observe technical data:
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: TRW
• Quality class: Q

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs SVHC: No information available, please contact the manufacturer!

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Manufacturer Restriction: ATE
• Length 1 [mm]: 155.2
• Length 2 [mm]: 156.4
• Height [mm]: 72.9
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Test Mark: E9 90R - 01107/708
• Observe technical data:
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: TRW
• Quality class: Q

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs SVHC: No information available, please contact the manufacturer!

• for PR number: 1LA
• Fitting Position: Front Axle
• Width 1 [mm]: 155.1
• Width 2 [mm]: 156.4
• Height [mm]: 72.8
• Thickness [mm]: 20
• Number of wear indicators [per axle]: 2
• Wear Warning Contact: incl. wear warning contact
• Warning Contact Length [mm]: 242.5
• Brake System: ATE
• Supplementary Article/Info 2: with anti-squeak plate
• Quality: PREMIUM
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: MEY

General Information: MEYLE-PD brake pads have a very short brake-in time, to ensure safe initial braking and high performance from the start. MEYLE-PD brake pads have a brake-in coating on the pad or are treated with scorching technology.

• Fitting Position: Rear Axle
• for PR number: 1KE
• for brake disc diameter [mm]: 300
• Quantity per packing unit: 4
• Brake System: TRW
• Supplementary Article/Supplementary Info: with accessories
• Width [mm]: 116
• Height [mm]: 59
• Height 1 [mm]: 59
• Thickness [mm]: 17.5
• WVA Number: 23326
• Test Mark: R90 Homologated
• Wear Warning Contact: not prepared for wear warning indicator
• Weight [kg]: 1.5
• Packing Type: Carton
• Packaging length [cm]: 16.8
• Packaging width [cm]: 9.7
• Packaging height [cm]: 6.2
• Number of threaded bolts: 4
• Manufacturer: JURID

Braking System: not for carbon-ceramic brake discs, only in conjunction with steel brake discs

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Thickness [mm]: 20
• Height [mm]: 73
• Wear Warning Contact: incl. wear warning contact
• Supplementary Article/Supplementary Info: with accessories
• Brake System: Teves
• Warning Contact Length [mm]: 210
• Width 1 [mm]: 156
• Width 2 [mm]: 155
• Supplementary Article/Info 2: with piston clip, with anti-squeak plate
• Number of wear indicators [per axle]: 2
• WVA Number: 23801, 23950
• Manufacturer: BREMBO
• Name: BR P 85 097

• Fitting Position: Front Axle
• for PR number: 1LJ
• Width 1 [mm]: 156
• Width 2 [mm]: 155
• Height [mm]: 72.9
• Thickness [mm]: 20.3
• Wear Warning Contact: with integrated wear sensor
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• Brake System: Teves
• Friction Lining Material: Ceramic
• Name: Piduriklotsi komplekt,ketaspidur
• Manufacturer: QUARO

• Fitting Position: Front Axle
• for PR number: 1LZ
• Quantity per packing unit: 4
• Brake System: LUCAS-GIRLING
• Width [mm]: 119
• Height [mm]: 70
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• for PR number: 1LB, 1LE, 1LT, 1LF
• Quantity per packing unit: 4
• Brake System: ATE-TEVES
• Width [mm]: 156
• Height [mm]: 74
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Fitting Position: Rear Axle
• Width [mm]: 116.1
• Height [mm]: 59
• Thickness [mm]: 17.4
• Supplementary Article/Info 2: with brake caliper screws
• Number of bolts/screws: 4
• Brake System: Lucas / TRW
• Test Mark: E1 90R-02A0498/0489
• MAPP code available:
• Article number of recommended accessories: 13.0460-0023.2
• Observe dimensions:
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: ATE
• Quality class: Q

Wear Warning Contact: prepared for wear warning indicator, excl. wear warning contact

• Fitting Position: Front Axle
• for PR number: 1LJ
• Width 1 [mm]: 156.3
• Width 2 [mm]: 155.1
• Height [mm]: 72.9
• Thickness [mm]: 20.3
• Wear Warning Contact: with integrated wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• WVA Number: 23950
• Brake System: Teves
• Article number of recommended accessories: 82071800
• Packaging length [cm]: 20.9
• Packaging width [cm]: 13.4
• Packaging height [cm]: 8.8
• Weight [kg]: 2.2
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: TEX

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Width 1 [mm]: 156.3
• Width 2 [mm]: 155.1
• Height [mm]: 72.9
• Thickness [mm]: 20.3
• Wear Warning Contact: with integrated wear warning contact
• Number of wear indicators [per axle]: 2
• Warning Contact Length [mm]: 210
• WVA Number: 23950
• Brake System: Teves
• Article number of recommended accessories: 8DZ 355 201-331
• Weight [kg]: 2.2
• Assy./disassy. by qualified personnel required!:
• Name: HE 8DB355011711
• Manufacturer: HELLA PAGID

• Fitting Position: Front Axle
• for PR number: 1LJ
• for brake disc diameter [mm]: 345
• Quantity per packing unit: 4
• Brake System: ATE
• Number of wear indicators [per axle]: 4
• Supplementary Article/Supplementary Info: without accessories
• Supplementary Article/Info 2: with piston clip
• Width [mm]: 155
• Width 1 [mm]: 156
• Height [mm]: 72.8
• Height 1 [mm]: 72.8
• Thickness [mm]: 20.2
• WVA Number: 23763, 23801
• Test Mark: R90 Homologated
• Wear Warning Contact: incl. wear warning contact
• Weight [kg]: 2.7
• Packing Type: Carton
• Number of springs: 2
• Packaging length [cm]: 21.4
• Packaging width [cm]: 16.2
• Packaging height [cm]: 9.7
• Manufacturer: JURID

• Fitting Position: Front Axle
• for PR number: 1LJ
• Quantity per packing unit: 4
• Brake System: ATE
• Width 1 [mm]: 155
• Width 2 [mm]: 156
• Height [mm]: 73
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• for PR number: 1LJ
• Fitting Position: Front Axle
• Height 1 [mm]: 155.1
• Width 1 [mm]: 72.9
• Height 2 [mm]: 156.3
• Width 2 [mm]: 72.9
• Thickness [mm]: 20.3
• Wear Warning Contact: incl. wear warning contact
• Warning Contact Length [mm]: 242.5
• Brake System: ATE
• Test Mark: E9 90R-02A1259/0708
• MAPP code available:
• Name: PIDURIKLOTSI KOMPLEKT,KETASPIDUR
• Manufacturer: ATE
• Quality class: Q

• Fitting Position: Rear Axle
• Quantity per packing unit: 4
• Braking System: Low dust brake pads
• Brake System: LUCAS-GIRLING
• Width [mm]: 87
• Height [mm]: 53
• Thickness [mm]: 17
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Supplementary Article/Info 2: with bolts/screws
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• for PR number: 1LB, 1LE, 1LT, 1LF
• Quantity per packing unit: 4
• Braking System: Low dust brake pads
• Brake System: ATE-TEVES
• Width [mm]: 156
• Height [mm]: 74
• Thickness [mm]: 20
• Wear Warning Contact: incl. wear warning contact
• Number of wear indicators [per axle]: 2
• Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
• Test Mark: ECE R90 APPROVED
• Manufacturer: ZIMMERMANN
