• Fitting Position: Rear Axle, Front
• Mounting Type: Rubber-Metal Mount
• Manufacturer: MERTZ

• Fitting Position: Lower, Lower Front Axle, inner
• Manufacturer: GSP ZAWIESZENIE

• Fitting Position: Rear Axle
• Manufacturer: FEBEST

• Required quantity: 2
• Length 2 [mm]: 50
• Inner Diameter [mm]: 14
• Outer Diameter [mm]: 53.3
• Fitting Position: both sides, inner, Rear Axle, Lower
• Weight [kg]: 0.19
• Control/Trailing Arm Type: for control arm
• Length 1 [mm]: 65
• Manufacturer: TEDGUM
• Additional information: TED99327 TEDGUM
• Lisainfo: TED99327 TEDGUM

• Fitting Position: Rear Axle both sides, inner, Lower
• Required quantity: 2
• paired article number: VKDS 438513
• Length [mm]: 48
• Height [mm]: 46.3
• Inner Diameter [mm]: 12.2
• Outer Diameter [mm]: 46.3
• Name: SK VKDS438513
• Manufacturer: SKF
• Lisainfo: SKFVKDS438513
• Additional information: SKFVKDS438513

• Fitting Position: Rear Axle Middle, outer
• Manufacturer: FEBEST

• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Fitting Position: both sides, Rear Axle, inner
• Axle alignment required after fitting:
• Manufacturer: VAICO

General Information: In the warranty, we always make a distinction between wear parts and vehicle parts. All wear parts are subject to a reduced warranty period and a maximum mileage. Brake components such as brake disks, brake pads, etc. maximum of 1000 km (break-in period). Therefore, warranty claims for brake parts are only reviewed with an installation invoice and a record of the wheel hub run-out measurement, including photos. For brake disks and brake pads, the break-in requirements specified by the vehicle manufacturer must be observed. When replacing brakes, the chassis components must always be checked with regard to clearance and the wheel hub with regard to wobble, and the appropriate documentation must be produced. If the vehicle is no longer in its original condition due to tuning work such as wheel accessories and tracking plates, the entitlement to make warranty claims is lost due to third-party work. The same warranty claims are lost if the vehicle is used for motor sports or similar events.

• Block Separation:
• Inner Diameter 1 [mm]: 12
• Outer Diameter 1 [mm]: 47
• Thickness 1 [mm]: 48
• Manufacturer: DELPHI
• Name: DE TD1616W

Fitting Position: Rear Axle, Lower, in front of axle, inner, Axle beam, Steering Knuckle, wheel suspension, outer

• Fitting Position: both sides, inner, outer, Rear Axle
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Name: Paigutus,rattalaagrikorpus
• Manufacturer: MAX

• Fitting Position: Rear Axle
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46.5
• for OE number: 33326763092
• Manufacturer: SASIC

• Thickness [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46
• Material: Rubber/Metal
• Control/Trailing Arm Type: for trailing arm
• Fitting Position: Rear Axle Left, Lower, Front, Rear Axle Right
• Shape: slotted
• Weight [kg]: 0.112
• Name: PUKS
• Manufacturer: FEB
• Additional information: FE32037
• Lisainfo: FE32037

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Installatsiooni pool: Tagasild vasakul, Tagasild paremal, all, kese
• Laius (mm): 55
• Siseläbimõõt [mm]: 14
• Välisläbimõõt [mm]: 47,3
• Manufacturer: MERTZ
• Lisainfo: M-S4411
• Additional information: M-S4411

• Fitting Position: Rear Axle Lower, Centre
• Manufacturer: GSP ZAWIESZENIE

• Thickness [mm]: 50
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• Fitting Position: Rear Axle Left, Rear Axle Right, outer
• Mounting Type: Rubber-Metal Mount
• Weight [kg]: 0.24
• Name: Puks - K„„ndmik BMW T. E87/90 LE/PR ZEWN.
• Manufacturer: FEB

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle, Lower
• Outer Diameter [mm]: 47.3
• Manufacturer: DENCKERMANN ZAWIESZENIE

• Thickness [mm]: 71
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46, 23
• Fitting Position: Front Axle Left, Lower, Rear, Front Axle Right
• Weight [kg]: 0.252
• Name: Puks - K„„ndmik BMW P. E87/90 TYLN
• Manufacturer: FEB

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle, Upper
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• for OE number: 33326765535
• paired article number: 2256091
• Manufacturer: SASIC

• Fitting Position: Rear Axle both sides, Upper, Rear
• Inner Diameter [mm]: 12.2
• Outer Diameter [mm]: 45.3
• Height [mm]: 48
• Name: ALT 87737AL
• Manufacturer: ALTE AUTOMOTIVE

• Fitting Position: Rear Axle both sides, outer
• Inner Diameter [mm]: 26.5
• Outer Diameter [mm]: 45.3
• Height [mm]: 49.5
• Name: ALT 87738AL
• Manufacturer: ALTE AUTOMOTIVE

• Thickness [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45, 26
• Fitting Position: Rear Axle Left, Upper, Rear, Rear Axle Right
• Mounting Type: Rubber-Metal Mount
• Weight [kg]: 0.232
• Name: Puks - K„„ndmik BMW T. E81/82/87/90 03- LE/PR
• Manufacturer: FEB

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle, Upper
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• for OE number: 33326765534
• Manufacturer: SASIC

• Fitting Position: Rear Axle, Upper, Front, outer, Centre, inner
• Block Separation:
• Inner Diameter [mm]: 12.1
• Outer Diameter [mm]: 45.2
• Width 1 [mm]: 50
• Width 2 [mm]: 33
• SVHC: No SVHC present!
• Manufacturer: FAG

• Kaal (kg): 0,234
• Installatsiooni pool: Tagasild mõlemapoolselt, üleval, väljas
• Laagritüüp: Kummi-metalllaager
• Roolimisliik: õõtshoova jaoks
• Siseläbimõõt [mm]: 12
• Välisläbimõõt [mm]: 45,2
• Pikkus (mm): 49,5
• Manufacturer: RTS

• Weight [kg]: 0.246
• Fitting Position: both sides, outer, Rear Axle Upper
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45.4
• Control/Trailing Arm Type: for semi-trailing arm, for control arm
• Length 2 [mm]: 33
• Required quantity: 2
• Length 1 [mm]: 49.5
• Manufacturer: TEDGUM

• Installatsiooni pool: esisild mõlemapoolselt, all, taga, sees
• Laagritüüp: Kummi-metalllaager
• Roolimisliik: für Längslenker
• Siseläbimõõt [mm]: 12,2
• Välisläbimõõt [mm]: 46,2
• Pikkus (mm): 71
• Kaal (kg): 0,256
• Manufacturer: RTS

• Fitting Position: Rear, Front Axle Left, Front Axle Right
• Height [mm]: 71
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46
• Supplementary Article/Supplementary Info: without holder
• Required quantity: 2
• replacement in pairs recommended:
• Name: Puks - K„„ndmik BMW P. E87/90 TYLN
• Manufacturer: MEY

• Fitting Position: Rear Axle, outer, both sides
• Required quantity: 2
• Height 1 [mm]: 49.6
• Height 2 [mm]: 33.3
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Manufacturer: OPTIMAL ZAWIESZENIE

• Kaal (kg): 0,112
• Installatsiooni pool: Tagasild mõlemapoolselt, all, ees
• Laagritüüp: Kummi-metalllaager
• Roolimisliik: õõtshoova jaoks
• Siseläbimõõt [mm]: 12
• Välisläbimõõt [mm]: 46
• Pikkus (mm): 48
• Manufacturer: RTS

• Thickness [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46
• Material: Rubber/Metal
• Control/Trailing Arm Type: for trailing arm
• Fitting Position: Rear Axle Left, Lower, Front, Rear Axle Right
• Shape: slotted
• Weight [kg]: 0.112
• Name: SW 20 93 2037
• Manufacturer: SWAG

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Front Axle, both sides, Rear, inner
• Mounting Type: Rubber-Metal Mount
• Outer Diameter [mm]: 46
• Inner Diameter [mm]: 12
• Name: Puks - K„„ndmik BMW P. E87/90 TYLN
• Manufacturer: MAX

• Fitting Position: Rear Axle, outer, Upper
• Inner Diameter 1 [mm]: 12
• Outer Diameter 1 [mm]: 45
• Thickness 1 [mm]: 50
• Manufacturer: DELPHI
• Name: DE TD1124W

• Fitting Position: Rear Axle, Lower
• Mounting Type: Rubber-Metal Mount
• Outer Diameter [mm]: 46.5
• Inner Diameter [mm]: 12
• Height [mm]: 47
• Guarantee: 3 years guarantee or up to 75,000km
• Manufacturer: METZGER

• Outer Diameter [mm]: 47.2
• Weight [kg]: 0.302
• Fitting Position: both sides, outer, Rear Axle, Lower
• Length 2 [mm]: 25
• Required quantity: 2
• Inner Diameter [mm]: 14
• Length 1 [mm]: 55
• Control/Trailing Arm Type: for control arm
• Name: Puks
• Manufacturer: TED

• Fitting Position: Rear, inner, Lower, Front Axle both sides
• Required quantity: 2
• Rod/Strut: for pull rod
• paired article number: VKDS 338543
• Name: SK VKDS338543
• Manufacturer: SKF

• Fitting Position: inner, Upper, Rear Axle Right, Rear Axle Left
• Height [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• Supplementary Article/Supplementary Info: without holder
• Required quantity: 2
• replacement in pairs recommended:
• Name: Puks - K„„ndmik BMW T. E81/82/87/90 03- LE/PR
• Manufacturer: MEY

• Fitting Position: Rear Axle, Rear, inner, outer
• Control/Trailing Arm Type: for control arm
• Outer Diameter [mm]: 46.5
• Width 1 [mm]: 25
• Width 2 [mm]: 48
• SVHC: No SVHC present!
• Manufacturer: FAG
• Name: LU 829057610

• Height [mm]: 50
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46
• Supplementary Article/Supplementary Info: without holder
• Required quantity: 2
• replacement in pairs recommended:
• Name: Puks - K„„ndmik BMW T. E87/90 LE/PR ZEWN.
• Manufacturer: MEY

Fitting Position: outer, Upper, Rear Axle Right, Rear Axle Left, Rear

• Block Separation:
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Manufacturer: LEMFORDER

Fitting Position: Rear Axle, Upper, both sides, Front, outer, Centre, inner SVHC: No information available, please contact the manufacturer!

• Fitting Position: inner, Front Axle Right, Front Axle Left
• Name: COC 49398162
• Manufacturer: CORTECO

• Fitting Position: both sides, Rear, Front Axle, Lower, inner
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46.3
• Required quantity: 2
• Length 1 [mm]: 71
• Length 2 [mm]: 42
• Control/Trailing Arm Type: for control arm
• Weight [kg]: 0.235
• Manufacturer: TEDGUM

• Fitting Position: Rear Axle both sides, Lower, inner
• Inner Diameter [mm]: 14.2
• Outer Diameter [mm]: 47.3
• Height [mm]: 53.9
• Name: ALT 84945AL
• Manufacturer: ALTE AUTOMOTIVE

• Fitting Position: Rear Axle Lower, both sides, inner
• Mounting Type: Rubber-Metal Mount
• Length [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 46
• Manufacturer: TRW

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Rear Axle, Upper, both sides, Front, inner
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Manufacturer: LEMFORDER

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Front Axle, both sides, Rear, inner
• Mounting Type: Rubber-Metal Mount
• Quantity per axle: 2
• Length [mm]: 71
• Outer Diameter [mm]: 46
• Inner Diameter [mm]: 12
• Name: Puks - K„„ndmik BMW P. E87/90 03- TYLNA
• Manufacturer: LMI

SVHC: No information available, please contact the manufacturer!

• Fitting Position: both sides, Rear Axle, Upper, inner, outer
• Control/Trailing Arm Type: for control arm
• Quantity per axle: 4
• Mounting Type: Rubber-Metal Mount
• Name: Puks - K„„ndmik BMW T.
• Manufacturer: LMI

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Front Axle, Rear, Lower
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 70
• for OE number: 31120393540
• Manufacturer: SASIC

• Fitting Position: Rear Axle Left, Rear Axle Right, Rear, outer
• Name: Puks - K„„ndmik BMW T. E81/88/90 04- LE/PR TYLNA
• Manufacturer: LMI

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Rear Axle, Upper
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• for OE number: Part of 33326777980
• paired article number: 2256090
• Manufacturer: SASIC
• Additional information: 2256091 SASIC
• Lisainfo: 2256091 SASIC

• Vehicle Equipment Line/Variant: EXC. XI - XD
• Fitting Position: mounting
• Mounting Type: Rubber-Metal Mount
• Name: Control arm bush left=right
• Quality class: PJ

Lisainfo: "Tootja: TEKNOROT
BMW 1 E87 '04-
(kvaliteediklass: PJ)" Additional information: "Tootja: TEKNOROT
BMW 1 E87 '04-
(kvaliteediklass: PJ)"

• Fitting Position: Rear Axle Lower, Rear, inner
• Manufacturer: FEBEST

• Fitting Position: Front Axle, both sides, Front, inner
• Mounting Type: Hydro Mount
• Control/Trailing Arm Type: for control arm
• Manufacturer: MERTZ

• Fitting Position: Front Axle, both sides, Front, inner
• Mounting Type: Hydro Mount
• Control/Trailing Arm Type: for control arm
• Manufacturer: MERTZ

• Fitting Position: Rear Axle
• Quantity Unit: Set
• Net weight [kg]: 0.36
• Name: Paigutus - K„„ndmik BMW T. E87/90 14X47X55 TYLNA
• Manufacturer: NK

• Fitting Position: Rear Axle, Upper, Front
• Mounting Type: Rubber-Metal Mount
• Control/Trailing Arm Type: for control arm
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• Guarantee: 3 years guarantee or up to 75,000km
• Manufacturer: METZGER

• Fitting Position: Rear Axle both sides, inner
• Required quantity: 2
• Rod/Strut: for camber strut
• paired article number: VKDS 438512
• Name: SK VKDS438512
• Manufacturer: SKF

• Fitting Position: Front Axle, Lower, Front
• Mounting Type: Hydro Mount
• Thickness [mm]: 76, 65
• Outer Diameter [mm]: 70
• Inner Diameter [mm]: 12
• Name: Puks - K„„ndmik BMW P. E87/90 PRZE
• Manufacturer: MAX

• Height [mm]: 48
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 45
• Supplementary Article/Supplementary Info: without holder
• Required quantity: 2
• replacement in pairs recommended:
• Name: Puks - K„„ndmik BMW T. E87/90
• Manufacturer: MEY

Fitting Position: inner, Upper, Rear Axle Right, Rear Axle Left, Rear

• Weight [kg]: 0.234
• Fitting Position: Rear Axle both sides, Upper, inner
• Mounting Type: Rubber-Metal Mount
• Control/Trailing Arm Type: for control arm
• Inner Diameter [mm]: 12.2
• Outer Diameter [mm]: 45.3
• Length [mm]: 48
• Manufacturer: RTS SA

• Fitting Position: Front Axle Left, Front Axle Right, Lower
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Lisainfo: Control Arm-/Trailing Arm Bush
• Additional information: Control Arm-/Trailing Arm Bush

• Fitting Position: Rear Axle Upper, Front, Rear, both sides, outer
• Mounting Type: Rubber-Metal Mount
• Control/Trailing Arm Type: for control arm
• Length [mm]: 33.2
• Overall Length [mm]: 44.5
• Outer Diameter [mm]: 42
• Inner Diameter [mm]: 12
• Manufacturer: TRW

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Rear Axle both sides, Lower, inner
• Inner Diameter [mm]: 14.2
• Outer Diameter [mm]: 47.3
• Height [mm]: 53.9
• Name: ALT 91108AL
• Manufacturer: ALTE AUTOMOTIVE

• Kaal (kg): 0,206
• Installatsiooni pool: Tagasild mõlemapoolselt, all, taga
• Laagritüüp: Kummi-metalllaager
• Roolimisliik: õõtshoova jaoks
• Siseläbimõõt [mm]: 14,2
• Välisläbimõõt [mm]: 53,3
• Pikkus (mm): 65
• Manufacturer: RTS

• Fitting Position: Front Axle Left, Front Axle Right, Upper
• Mounting Type: Hydro Mount
• Lisainfo: Rubber mount for wishbone, front
• Additional information: Rubber mount for wishbone, front

• Fitting Position: Front Axle, Lower, Front
• Inner Diameter [mm]: 12.2
• Outer Diameter [mm]: 70
• Height [mm]: 76
• Name: ALT 89062AL
• Manufacturer: ALTE AUTOMOTIVE

• Fitting Position: Rear Axle Lower, Upper, outer, Centre
• Manufacturer: FEBEST

• Fitting Position: outer, Rear, Lower, Rear Axle, both sides
• Height [mm]: 54
• Inner Diameter [mm]: 14.2
• Outer Diameter [mm]: 47
• Control/Trailing Arm Type: for control arm
• Mounting Type: Rubber-Metal Mount
• Bearing Type: Uniball pivot bearing
• Manufacturer: OPTIMAL ZAWIESZENIE

• Fitting Position: Rear Axle Right, Rear Axle Left, Lower, outer
• Manufacturer: CORTECO
• Name: COC 49398521

• Fitting Position: inner, Lower, Front, Front Axle both sides
• Required quantity: 2
• Rod/Strut: for pull rod
• paired article number: VKDS 338500
• Height [mm]: 76
• Inner Diameter [mm]: 12.2
• Outer Diameter [mm]: 70
• Manufacturer: SKF
• Name: SK VKDS338500

• Width [mm]: 55
• Inner Diameter [mm]: 14
• Outer Diameter [mm]: 47.3
• Fitting Position: Rear Axle Left, Lower, Centre, Rear Axle Right
• Weight [kg]: 0.36
• Name: Paigutus - K„„ndmik BMW T. E87/90 14X47X55 TYLNA
• Manufacturer: FEB
• Additional information: F26643
• Lisainfo: F26643

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Front Axle, Lower, Front
• Inner Diameter 1 [mm]: 12
• Outer Diameter 1 [mm]: 70
• Thickness 1 [mm]: 76
• Manufacturer: DELPHI
• Name: DE TD861W

• Fitting Position: inner, Left, Right, Front, Front Axle
• Material: Metal
• Weight [g]: 341
• Inner Diameter [mm]: 12
• Outer Diameter [mm]: 56
• Length [mm]: 40
• Overall Length [mm]: 47.35
• Name: IM 1367
• Manufacturer: ORIGINAL IMPERIUM

General Information: The installation of this product can be performed only in a workshop environment by trained professionals

• Fitting Position: Front Axle, both sides, Front, inner
• Mounting Type: Hydro Mount
• Control/Trailing Arm Type: for control arm
• Name: Puks - K„„ndmik VW P. E81/87/90/91 05-
• Manufacturer: MAX
