• Width [mm]: 10
• Height [mm]: 17.5
• External Thread [mm]: M10 x 1
• Material: Plastic
• Supplementary Article/Info 2: with seal ring
• Fabrication Number: CZW-BM-034
• Manufacturer: NTY

• Length 1 [mm]: 10
• Length 2 [mm]: 17.5
• External Thread [mm]: M10 x 1
• Material: Plastic
• Name: OHUTUSKRUVI/-KLAPP, RADIAATOR
• Manufacturer: MAX

• Quantity per packing unit: 100
• for OE number: 17 11 1 712 788
• Manufacturer: TRUCKTEC

• Quantity per packing unit: 50
• Length [mm]: 10
• Material: Plastic
• External Thread [mm]: M10x1
• Manufacturer: VAICO

General Information: In the warranty, we always make a distinction between wear parts and vehicle parts. All wear parts are subject to a reduced warranty period and a maximum mileage. Brake components such as brake disks, brake pads, etc. maximum of 1000 km (break-in period). Therefore, warranty claims for brake parts are only reviewed with an installation invoice and a record of the wheel hub run-out measurement, including photos. For brake disks and brake pads, the break-in requirements specified by the vehicle manufacturer must be observed. When replacing brakes, the chassis components must always be checked with regard to clearance and the wheel hub with regard to wobble, and the appropriate documentation must be produced. If the vehicle is no longer in its original condition due to tuning work such as wheel accessories and tracking plates, the entitlement to make warranty claims is lost due to third-party work. The same warranty claims are lost if the vehicle is used for motor sports or similar events.

• Thread Size: M10 x 1
• Material: Plastic
• Supplementary Article/Supplementary Info: with gasket/seal
• Manufacturer: AIC

General Information: Our products are usually delivered without installation instructions. Installation may only be carried out by trained specialist technicians. Products supplied by us are exclusively intended for proper and appropriate use. The warranty is void in the event of improper, contrary to the intended purpose or unsuitable application or use. For electronic items that leave fault memory entries, it is essential to submit fault memory logs in the event of a claim. This consequently concerns all electronic items that are detected, monitored and controlled by the engine control unit, such as sensors of all kinds (e.g. NOX sensors, ABS sensors), mass airflow sensors, airbag slip rings, headlamp levelling control units, throttle valves, lambda sensors or EGR modules. If you encounter difficulties during a repair (troubleshooting max. 1 hr.), please contact technical support at: Phone: 040 - 25 30 66 55 Email: service@aic-germany.de This often avoids extensive troubleshooting that is disproportionate to normal repair times. The following applies to complaints: The more complete the processes are submitted, the faster they can be processed. Complete documentation includes the warranty application (incl. KBA no., chassis no., first registration, engine code, mileage), first and second installation invoice, fault memory log, guided troubleshooting and, if applicable, pictures. Incomplete documentation may result in rejection of the claim.

• Fitting Position: Radiator
• Thread Size: M10x1
• Thread Length [mm]: 12.4
• Total Length [mm]: 17.4
• Material: Plastic
• Bolt Head-/Nut Design: Slot
• Supplementary Article/Info 2: with seal ring
• Manufacturer: METZGER

Seal Material: EPDM (ethylene propylene diene Monomer (M-class) rubber)

• Length [mm]: 10, 17.5
• External Thread Size: M10 x 1
• Material: Plastic
• Weight [kg]: 0.005
• Supplementary Article/Info 2: with seal ring
• Name: OHUTUSKRUVI/-KLAPP, RADIAATOR
• Manufacturer: FEB

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Pressure [bar]: 2
• Manufacturer: ASHIKA
• Lisainfo: 33-00-014
• Additional information: 33-00-014

• Pressure [bar]: 2
• Manufacturer: JAPKO

• Pressure [bar]: 1.4
• Manufacturer: ASHIKA

• Pressure [bar]: 1.4
• Manufacturer: JAPKO

• Material: Aluminium
• Core Length [mm]: 440
• Core Width [mm]: 322
• Core Depth [mm]: 34
• Version: Alternative
• Radiator type: Mechanically jointed cooling fins
• Name: RADIAATOR,MOOTORIJAHUTUS
• Manufacturer: NRF
• Lisainfo: 440*322*34
• Additional information: 440*322*34

• Name: Radiator
• Quality class: ZJ

Lisainfo: 3 E36 91- (kvaliteediklass ZJ)

• Vehicle Equipment: for vehicles without air conditioning
• Transmission Type: Manual Transmission
• Cooling fins material: Aluminium
• Core Depth [mm]: 34
• Core Length [mm]: 440
• Core Width [mm]: 322
• Radiator type: Mechanically jointed cooling fins
• Water Tank Material (radiator): Plastic

• Netopikkus [mm]: 440
• Netolaius [mm]: 329
• Netosügavus [mm]: 32
• Seerianumber: CCH-BM-030
• Manufacturer: NTY

• Radiator type: Mechanically jointed cooling fins
• Cooling fins material: Aluminium
• Water Tank Material (radiator): Plastic
• Core Depth [mm]: 34
• Core Length [mm]: 440
• Core Width [mm]: 322
• Manufacturer: KAMOKA

• Core Length [mm]: 440
• Core Width [mm]: 322
• Core Depth [mm]: 34
• Transmission Type: Manual Transmission
• Vehicle Equipment: for vehicles without air conditioning
• Water Tank Material (radiator): Plastic
• Cooling fins material: Aluminium
• Assy./disassy. by qualified personnel required!:
• Name: AB 004-017-0004
• Manufacturer: ABAKUS

General Information: The following information is for general and informational purposes only and does not constitute warranty terms. Warranty terms and conditions are available from our dealers and in our general terms and conditions of sale. Abakus spare/repair parts are intended only for vehicle repairs in order to restore their original functionality. Abakus spare/repair parts are used or sold to users only for the purpose of repairing vehicles to restore their original look and functionality and are not original/genuine/OE/OEM/OES replacement parts. These items do not originate from the vehicle manufacturer and may be the subject of a design not owned by Abakus and the manufacturer of this spare part. They may only be used for repairs to restore the intended vehicle to its original appearance. Our products are delivered without instruction of installation. Installation of our product may only be carried out by trained specialist technicians in specific car repairs. Products supplied by us are exclusively intended for proper and appropriate use. The warranty may become invalid in the event of: improper installation or repair, unsuitable application or use, installation or repair made outside specialist car workshops. Warranty claims are lost if the vehicle is modified and used for motor sports, tuning or similar events (except our tuning parts which are described in TecDoc and on our price list). Warranty application should include complete documentation among others: chassis no., first registration, vehicle mileage, information about LPG installation, fault memory log, pictures, our QC (quality check) code, installation invoice, contact details of the car repair workshop performing the replacement or repair. Warranty application are available in our Client Panel system. Complaints may require supplementing data such as error memory logs. Incomplete documentation may result in rejection of the claim. Any damage caused during transport is not considered quality damage and will be considered on an individual basis. The product is intended for use within the performance limits specified by the manufacturer and should only be used by qualified personnel who have been trained to operate this product. Before each use, the product should be checked for damage or fixing of its parts and not used if any defects or loose parts are found. Failure to follow the manufacturer's guidelines could result in potential product damage or even injury. Wear appropriate protective clothing if necessary when working with the product.

• Material: Aluminium
• Core Length [mm]: 440
• Core Width [mm]: 326
• Core Depth [mm]: 34
• Supplementary Article/Info 2: with mounting parts
• Radiator type: Brazed cooling fins
• Name: RADIAATOR,MOOTORIJAHUTUS
• Manufacturer: NRF
• Lisainfo: 440*326*34
• Additional information: 440*326*34

• Name: Radiator
• Quality class: ZJ

Lisainfo: 5 E34 88-95 (kvaliteediklass ZJ)

• Core Depth [mm]: 32
• Core Length [mm]: 440
• Core Width [mm]: 330
• Radiator type: Brazed cooling fins
• Water Tank Material (radiator): Plastic
• Name: Radiator
• Quality class: PJ

Lisainfo: 3 E36 91- (kvaliteediklass PJ) Additional information: 3 E36 91- (kvaliteediklass PJ)

• Vehicle Equipment: for vehicles without air conditioning
• Transmission Type: Manual Transmission
• Cooling fins material: Aluminium
• Core Depth [mm]: 34
• Core Length [mm]: 440
• Core Width [mm]: 322
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Mechanically jointed cooling fins
• Supplementary Article/Info 2: without expansion tank
• Supplementary Article/Supplementary Info: without gasket/seal
• Water Tank Material (radiator): Plastic
• Manufacturer: NISSENS
• Name: NI 60735A
• Lisainfo: BMW 5 E34 (88-) 525 ix
• Additional information: BMW 5 E34 (88-) 525 ix

• Engine Code: M40 B18 (184E1)
• Vehicle Equipment: for vehicles without air conditioning
• Transmission Type: 5-Speed Manual Transmission
• Core Length [mm]: 440
• Core Width [mm]: 340
• Core Depth [mm]: 32
• Radiator type: Mechanically jointed cooling fins
• Technical Information: Aluminium core with plastyic tanks
• Name: MM BM240
• Manufacturer: MAGNETI MARELLI

• Transmission Type: Manual Transmission
• Vehicle Equipment: for vehicles without air conditioning
• Construction Year from: 04.1993
• Construction Year to: 04.1994
• Core Depth [mm]: 32
• Core Length [mm]: 440
• Core Width [mm]: 318
• Radiator type: Brazed cooling fins
• Water Tank Material (radiator): Plastic
• Quality class: PJ
• Name: Radiator

• Transmission Type: Manual Transmission
• Vehicle Equipment: for vehicles with air conditioning
• Core Depth [mm]: 32
• Core Length [mm]: 520
• Core Width [mm]: 438
• Radiator type: Brazed cooling fins
• Water Tank Material (radiator): Plastic
• Name: Radiator
• Quality class: PJ

Lisainfo: 5 E34 88-95 (kvaliteediklass PJ) Additional information: 5 E34 88-95 (kvaliteediklass PJ)

• Core Length [mm]: 520
• Core Width [mm]: 435
• Core Depth [mm]: 32
• Transmission Type: Manual Transmission
• Vehicle Equipment: for vehicles without air conditioning
• Water Tank Material (radiator): Plastic
• Cooling fins material: Aluminium
• Assy./disassy. by qualified personnel required!:
• Manufacturer: ABAKUS LORO

General Information: The following information is for general and informational purposes only and does not constitute warranty terms. Warranty terms and conditions are available from our dealers and in our general terms and conditions of sale. Abakus spare/repair parts are intended only for vehicle repairs in order to restore their original functionality. Abakus spare/repair parts are used or sold to users only for the purpose of repairing vehicles to restore their original look and functionality and are not original/genuine/OE/OEM/OES replacement parts. These items do not originate from the vehicle manufacturer and may be the subject of a design not owned by Abakus and the manufacturer of this spare part. They may only be used for repairs to restore the intended vehicle to its original appearance. Our products are delivered without instruction of installation. Installation of our product may only be carried out by trained specialist technicians in specific car repairs. Products supplied by us are exclusively intended for proper and appropriate use. The warranty may become invalid in the event of: improper installation or repair, unsuitable application or use, installation or repair made outside specialist car workshops. Warranty claims are lost if the vehicle is modified and used for motor sports, tuning or similar events (except our tuning parts which are described in TecDoc and on our price list). Warranty application should include complete documentation among others: chassis no., first registration, vehicle mileage, information about LPG installation, fault memory log, pictures, our QC (quality check) code, installation invoice, contact details of the car repair workshop performing the replacement or repair. Warranty application are available in our Client Panel system. Complaints may require supplementing data such as error memory logs. Incomplete documentation may result in rejection of the claim. Any damage caused during transport is not considered quality damage and will be considered on an individual basis. The product is intended for use within the performance limits specified by the manufacturer and should only be used by qualified personnel who have been trained to operate this product. Before each use, the product should be checked for damage or fixing of its parts and not used if any defects or loose parts are found. Failure to follow the manufacturer's guidelines could result in potential product damage or even injury. Wear appropriate protective clothing if necessary when working with the product.

• Transmission Type: Manual Transmission
• Vehicle Equipment: for vehicles without air conditioning
• Core Length [mm]: 440
• Core Width [mm]: 326
• Core Depth [mm]: 34
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Brazed cooling fins
• Packaging length [cm]: 78.5
• Packaging width [cm]: 61.5
• Packaging height [cm]: 13.5
• Weight [kg]: 3.24
• Manufacturer: AKSDASIS

• Material: Aluminium
• Core Length [mm]: 521
• Core Width [mm]: 435
• Core Depth [mm]: 34
• Supplementary Article/Info 2: with mounting parts
• Radiator type: Brazed cooling fins
• Name: RADIAATOR,MOOTORIJAHUTUS
• Manufacturer: NRF
• Lisainfo: 521*435*34
• Additional information: 521*435*34

• Core Length [mm]: 440
• Core Width [mm]: 328
• Core Depth [mm]: 40
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Brazed cooling fins
• Packaging length [cm]: 70
• Packaging width [cm]: 41.4
• Packaging height [cm]: 11.7
• Weight [kg]: 3.38
• Manufacturer: AKSDASIS

• Transmission Type: Manual Transmission
• Core Length [mm]: 520
• Core Width [mm]: 327
• Core Depth [mm]: 30
• Radiator type: Brazed cooling fins
• Water Tank Material (radiator): Plastic
• Cooling fins material: Aluminium
• reinforced version:
• Packaging length [cm]: 78.5
• Packaging width [cm]: 39.5
• Packaging height [cm]: 11.2
• Weight [kg]: 3.8
• Manufacturer: AKSDASIS

Vehicle Equipment: for vehicles with automatic climate control, for vehicles with/without air conditioning

• Vehicle Equipment: for vehicles with air conditioning
• Transmission Type: Manual Transmission
• Block Separation:
• Cooling fins material: Aluminium
• Core Depth [mm]: 34
• Core Length [mm]: 520
• Core Width [mm]: 435
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Mechanically jointed cooling fins
• Supplementary Article/Info 2: without expansion tank
• Water Tank Material (radiator): Plastic

• Cooling fins material: Aluminium
• Core Depth [mm]: 34
• Core Length [mm]: 520
• Core Width [mm]: 435
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Mechanically jointed cooling fins
• Supplementary Article/Info 2: without expansion tank
• Water Tank Material (radiator): Plastic

• Transmission Type: Manual Transmission, Automatic Transmission
• Vehicle Equipment: for vehicles with automatic climate control
• Core Length [mm]: 520
• Core Width [mm]: 440
• Core Depth [mm]: 30
• Inlet Ø [mm]: 41
• Outlet Ø [mm]: 41
• Radiator type: Mechanically jointed cooling fins
• reinforced version:
• Packaging length [cm]: 78
• Packaging width [cm]: 50
• Packaging height [cm]: 11.5
• Weight [kg]: 4.84
• Manufacturer: AKSDASIS

• Cooling fins material: Aluminium
• Core Depth [mm]: 32
• Core Length [mm]: 520
• Core Width [mm]: 439
• Inlet Ø [mm]: 40
• Outlet Ø [mm]: 40
• Radiator type: Brazed cooling fins
• Supplementary Article/Info 2: without top, with expansion tank
• Supplementary Article/Supplementary Info: without gasket/seal
• Water Tank Material (radiator): Plastic
• Manufacturer: NISSENS
• Lisainfo: BMW 5 E34 (88-) 525 ix
• Additional information: BMW 5 E34 (88-) 525 ix

Installation Information: FIRST FIT - a time-saving installation! Find all additional parts such as caps, gaskets, nuts, clamps, plugs, bolts, fittings, screws and other parts in the box

• Radiator type: Brazed cooling fins
• Core Length [mm]: 520
• Core Width [mm]: 436
• Core Depth [mm]: 32
• Water Tank Material (radiator): Plastic
• Additionally required articles (article numbers): CRB 22 000P
• Manufacturer: produced by MAHLE
• Transmission Type: Manual Transmission
• Packaging width [cm]: 12
• Net Weight [g]: 4,517
• Packaging height [cm]: 61.5
• Packaging length [cm]: 85
• Name: Radiaator,mootorijahutus

General Information: The core dimensions / product measurements of the different manufacturers /vendors might be different due to various production technologies. These dimensions / product measurements are not an indication for the performance or the correct fitting accuracy of the product itself.
