• Construction Year from: 08.1985
• Construction Year to: 08.1990
• Braking/Driving Dynamics: for vehicles with ABS
• Brake Disc Type: solid
• Outer Diameter [mm]: 258
• Brake Disc Thickness [mm]: 16
• Fitting Position: Front Axle
• Height [mm]: 95
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 112
• Centering Diameter [mm]: 45.2
• Minimum thickness [mm]: 13
• Name: PIDURIKETAS
• Manufacturer: MAX

• Brake Disc Thickness [mm]: 16
• Rim Hole Number: 5
• Thickness [mm]: 92
• Outer Diameter [mm]: 258
• Bolt Hole Circle Ø [mm]: 112
• Surface: Coated
• Brake Disc Type: solid
• Fitting Position: Front Axle
• Minimum thickness [mm]: 13
• Centering Diameter [mm]: 45
• Weight [kg]: 8.737
• Observe service information:
• Manufacturer: FEBI BILSTEIN
• Quantity per packing unit: 2

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Brake Caliper Type: Fist-type Caliper
• Braking/Driving Dynamics: for vehicles without ABS
• Construction Year from: 08.1985
• Fitting Position: Front Axle
• Brake Disc Type: solid
• Outer Diameter [mm]: 258
• Hub Diameter [mm]: 167
• Centering Diameter [mm]: 60
• Brake Disc Thickness [mm]: 16
• Height 1 [mm]: 59
• Height 2 [mm]: 95.5
• Bolt Hole Circle Ø [mm]: 112
• Rim Hole Number: 5
• Replace in pairs only:
• Manufacturer: TOPRAN

General Information: Any and all spare parts we supply are solely intended for the designated purpose as defined by us. Installation by trained personnel only. Our products are usually supplied without assembly instructions. Installation in vehicles other than those specified by us may lead to the exclusion of warranty.

• Fitting Position: Front Axle
• Braking/Driving Dynamics: for vehicles without ABS, for vehicles with ABS
• Block Separation:
• Construction Year from: 07.1986
• Construction Year to: 12.1990
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Number of Holes: 5
• Test Mark: E1 90R-02C0527/2008
• Surface: Oiled
• Outer Diameter [mm]: 258
• Brake Disc Thickness [mm]: 16
• Minimum thickness [mm]: 13
• Centering Diameter [mm]: 67.9
• Height [mm]: 92.3
• Manufacturer: DELPHI LOCKHEED HAMULCE

• Construction Year to: 07.1985
• Brake Disc Type: solid
• Outer Diameter [mm]: 278
• Brake Disc Thickness [mm]: 12.9
• Fitting Position: Front Axle
• Height [mm]: 118.7
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 112
• Minimum thickness [mm]: 11
• Centering Diameter [mm]: 45
• Name: PIDURIKETAS
• Manufacturer: MAX

• Vehicle Identification Number (VIN) from: 24-G-000 001
• Fitting Position: Front Axle
• Outer Diameter [mm]: 258
• Height [mm]: 95
• Brake Disc Thickness [mm]: 16
• Minimum thickness [mm]: 13
• Centering Diameter [mm]: 45.2
• Bolt Hole Circle Ø [mm]: 112
• Number of Holes: 5
• Brake Disc Type: solid
• Thread Size: M14x1,5
• Required quantity: 2
• Name: PIDURIKETAS
• Manufacturer: MEY

• Fitting Position: Front Axle
• Brake Caliper Type: Fist-type Caliper
• Outer Diameter [mm]: 257.7
• Brake Disc Thickness [mm]: 16
• Minimum thickness [mm]: 13
• Height [mm]: 94.8
• Bolt Hole Circle Ø [mm]: 112
• Brake Disc Type: solid
• Centering Diameter [mm]: 45.2
• Number of Holes: 5
• Surface: Oiled
• Manufacturer: BOSCH UK£ADY HAMULCOWE
• Lisainfo: 0986478224 BOSCH
• Additional information: 0986478224 BOSCH

• Fitting Position: Front Axle
• Construction Year from: 08.1985
• Construction Year to: 08.1990
• Braking/Driving Dynamics: for vehicles with ABS
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Outer Diameter [mm]: 258
• Brake Disc Thickness [mm]: 16
• Minimum thickness [mm]: 13
• Height [mm]: 95
• Number of Holes: 5
• Thread Size: M14 x 1.50
• Bolt Hole Circle Ø [mm]: 112
• Centering Diameter [mm]: 45.2
• Colour: black
• Surface: painted
• Name: PIDURIKETAS
• Manufacturer: TRW

SVHC: No information available, please contact the manufacturer!

• Brake Caliper Type: Fixed Caliper
• Fitting Position: Front Axle
• Brake Disc Hub Height [mm]: 106.1
• Rim Hole Number: 5
• Height [mm]: 118.5
• Brake Disc Type: solid
• Brake Disc Thickness [mm]: 13
• Minimum thickness [mm]: 11
• Outer Diameter [mm]: 278
• Centering Diameter [mm]: 45.2
• Bolt Hole Circle Ø [mm]: 112
• Manufacturer: VAICO

General Information: In the warranty, we always make a distinction between wear parts and vehicle parts. All wear parts are subject to a reduced warranty period and a maximum mileage. Brake components such as brake disks, brake pads, etc. maximum of 1000 km (break-in period). Therefore, warranty claims for brake parts are only reviewed with an installation invoice and a record of the wheel hub run-out measurement, including photos. For brake disks and brake pads, the break-in requirements specified by the vehicle manufacturer must be observed. When replacing brakes, the chassis components must always be checked with regard to clearance and the wheel hub with regard to wobble, and the appropriate documentation must be produced. If the vehicle is no longer in its original condition due to tuning work such as wheel accessories and tracking plates, the entitlement to make warranty claims is lost due to third-party work. The same warranty claims are lost if the vehicle is used for motor sports or similar events.

• Fitting Position: Front Axle
• Vehicle type: Campmobile, Transporter, Caravelle
• Block Separation:
• Brake Caliper Type: Floating Caliper
• Construction Year from: 07.1986
• Välisläbimõõt [mm]: 258
• Pidurikettajämedus [mm]: 16
• Miinimumjämedus (mm): 13
• Kõrgus (mm): 95,5
• Veljeaukude hulk: 5
• Piduriketta liik: täis
• Tsentri läbimõõt (mm): 45
• Ava Ø (mm): 112
• Keskaugu läbimõõt (mm): 168
• Kaal (kg): 7,94
• Montaažiinfo: Important: Observe Fitting Instructions
• Manufacturer: ABS

• Construction Year to: 06.1986
• Fitting Position: Front Axle
• Brake Disc Type: solid
• Outer Diameter [mm]: 278
• Brake Disc Thickness [mm]: 13
• Number of Holes: 5
• Brake Caliper Type: Fixed Caliper
• Surface: Coated
• Lisainfo: Brake Disc
• Additional information: Brake Disc

• Vehicle Identification Number (VIN) to: ******24*G*120000
• Brake Disc Thickness [mm]: 13
• Rim Hole Number: 5
• Outer Diameter [mm]: 278
• Bolt Hole Circle Ø [mm]: 112
• Surface: Coated
• Brake Disc Type: solid
• Fitting Position: Front Axle
• Weight [kg]: 8.564
• Observe service information:
• Manufacturer: FEBI BILSTEIN
• Quantity per packing unit: 2
• Lisainfo: 02584 FEBI
• Additional information: 02584 FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Front Axle
• Brake Caliper Type: Fixed Caliper
• Vehicle type: Transporter, Caravelle
• Block Separation:
• Construction Year to: 06.1986
• Välisläbimõõt [mm]: 278
• Pidurikettajämedus [mm]: 13
• Miinimumjämedus (mm): 11
• Kõrgus (mm): 118,6
• Veljeaukude hulk: 5
• Piduriketta liik: täis
• Tsentri läbimõõt (mm): 45
• Ava Ø (mm): 112
• Keskaugu läbimõõt (mm): 162
• Kaal (kg): 8,64
• Montaažiinfo: Important: Observe Fitting Instructions
• Manufacturer: ABS

• Vehicle Identification Number (VIN) to: 24-G-200 000
• Fitting Position: Front Axle
• Outer Diameter [mm]: 278
• Height [mm]: 119
• Brake Disc Thickness [mm]: 13
• Minimum thickness [mm]: 11
• Centering Diameter [mm]: 45.2
• Bolt Hole Circle Ø [mm]: 112
• Number of Holes: 5
• Brake Disc Type: solid
• Thread Size: M14x1,5
• Required quantity: 2
• Name: PIDURIKETAS
• Manufacturer: MEY

• Brake Caliper Type: Fixed Caliper
• Construction Year to: 06.1986
• not for country specific design: Sweden
• Fitting Position: Front Axle
• Brake Disc Type: solid
• Outer Diameter [mm]: 278
• Hub Diameter 1 [mm]: 164
• Hub Diameter 2 [mm]: 60
• Brake Disc Thickness [mm]: 13
• Height 1 [mm]: 82
• Height 2 [mm]: 119
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 112
• Centering Diameter [mm]: 45.2
• Replace in pairs only:
• Manufacturer: TOPRAN

General Information: Any and all spare parts we supply are solely intended for the designated purpose as defined by us. Installation by trained personnel only. Our products are usually supplied without assembly instructions. Installation in vehicles other than those specified by us may lead to the exclusion of warranty.

• Fitting Position: Front Axle
• Construction Year from: 08.1985
• Brake Disc Type: solid
• Outer Diameter [mm]: 258
• Brake Disc Thickness [mm]: 16
• Height [mm]: 95.5
• Minimum thickness [mm]: 13
• Inner Diameter [mm]: 1
• Bolt Hole Circle Ø [mm]: 112
• Centering Diameter [mm]: 45.2
• Hole Arrangement/Number: 05/05
• Wheel Bolt Bore Diameter [mm]: 14
• Packaging length [cm]: 27.8
• Packaging width [cm]: 27.8
• Packaging height [cm]: 12.2
• Weight [kg]: 7.8
• Name: PIDURIKETAS
• Manufacturer: TEX
• Quantity per packing unit: 2

Supplementary Article/Info 2: with wheel hub, without wheel bearing, without wheel studs

• Construction Year from: 08.1985
• Brake Caliper Type: Fist-type Caliper
• Fitting Position: Front Axle
• Quantity per packing unit: 2
• Välisläbimõõt [mm]: 258
• Pidurikettajämedus [mm]: 16
• Miinimumjämedus (mm): 13
• Piduriketta liik: täis
• Aukude arv: 5
• Pealispind: kaetud
• Ava Ø (mm): 112
• Kõrgus (mm): 95,5
• Tsentri läbimõõt (mm): 45,2
• Siseläbimõõt [mm]: 67,9
• Keermemõõt: M14x1,5
• MAPP-code olemas:
• Name: PIDURIKETAS
• Manufacturer: ATE
• Quality class: Q

• Vehicle Identification Number (VIN) to: 24-G-200000
• Brake Caliper Type: Fixed Caliper
• Fitting Position: Front Axle
• Välisläbimõõt [mm]: 278
• Pidurikettajämedus [mm]: 13
• Miinimumjämedus (mm): 11
• Piduriketta liik: täis
• Aukude arv: 5
• Ava Ø (mm): 112
• Kõrgus (mm): 118,5
• Tsentri läbimõõt (mm): 45,2
• Siseläbimõõt [mm]: 136,3
• Keermemõõt: M14x1,5
• MAPP-code olemas:
• Name: Piduriketas
• Manufacturer: ATE
• Quantity per packing unit: 2

• Fitting Position: Front Axle
• Brake Caliper Type: Fixed Caliper
• Outer Diameter [mm]: 278
• Brake Disc Thickness [mm]: 13
• Minimum thickness [mm]: 11
• Height [mm]: 118.5
• Bolt Hole Circle Ø [mm]: 112
• Brake Disc Type: solid
• Centering Diameter [mm]: 67.9
• Number of Holes: 5
• Surface: Oiled
• fulfils ECE norm: ECE-R90
• Manufacturer: BOSCH HAMULCE

• Fitting Position: Front Axle
• Construction Year to: 07.1985
• Surface: painted
• Brake Disc Type: solid
• Outer Diameter [mm]: 278
• Brake Disc Thickness [mm]: 12.9
• Minimum thickness [mm]: 11
• Centering Diameter [mm]: 45.2
• Height [mm]: 118.7
• Number of Holes: 5
• Thread Size: M14 x 1,5
• Bolt Hole Circle Ø [mm]: 112
• Colour: black
• Test Mark: E1 90R-02 C0950/0738
• Name: PIDURIKETAS
• Manufacturer: TRW

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Front Axle
• Brake Caliper Type: Fixed Caliper
• Brake Disc Type: solid
• Brake Disc Thickness [mm]: 13
• Number of Holes: 5
• Height [mm]: 119
• Centering Diameter [mm]: 45
• Outer Diameter [mm]: 278
• Minimum thickness [mm]: 11
• Manufacturer: BREMBO
• Name: BR 08.2981.10

• Fitting Position: Front Axle
• Brake Disc Type: solid
• Surface: Coated
• Outer Diameter [mm]: 278
• Brake Disc Thickness [mm]: 13
• Height [mm]: 119
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 112
• Wheel Hub Diameter 1 [mm]: 45
• Wheel Hub Diameter 2 [mm]: 68
• Supplementary Article/Info 2: without wheel bearing, without ABS sensor ring
• Minimum thickness [mm]: 11
• Weight [kg]: 8.53
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN
