Description
In stock
Price
(incl. VAT)
- Inner Diameter [mm]: 55
- Outer Diameter [mm]: 68
- Height [mm]: 8.5
-
Material: NBR
(nitrile butadiene rubber) - Dust Cover: with dust lip
- Fitting Position: Front Axle both sides
- Manufacturer: TOPRAN
General Information: Any and all spare parts we supply are solely intended for the designated purpose as defined by us. Installation by trained personnel only. Our products are usually supplied without assembly instructions. Installation in vehicles other than those specified by us may lead to the exclusion of warranty.
-
Vehicle Identification Number (VIN) from: 24-
E- 023828 - Fitting Position: Front Axle
-
Width [mm]: 16.6,
18 -
Outer Diameter [mm]: 68,
45 - Height [mm]: 17
-
Inner Diameter [mm]: 41,
22 -
Width 2 [mm]: 15.5,
17.5 - Weight [kg]: 0.128
- Manufacturer: VAICO
General Information: In the warranty, we always make a distinction between wear parts and vehicle parts. All wear parts are subject to a reduced warranty period and a maximum mileage. Brake components such as brake disks, brake pads, etc. maximum of 1000 km (break-in period). Therefore, warranty claims for brake parts are only reviewed with an installation invoice and a record of the wheel hub run-out measurement, including photos. For brake disks and brake pads, the break-in requirements specified by the vehicle manufacturer must be observed. When replacing brakes, the chassis components must always be checked with regard to clearance and the wheel hub with regard to wobble, and the appropriate documentation must be produced. If the vehicle is no longer in its original condition due to tuning work such as wheel accessories and tracking plates, the entitlement to make warranty claims is lost due to third-party work. The same warranty claims are lost if the vehicle is used for motor sports or similar events.
-
Fitting Position: Front Axle,
inner -
Lisainfo: Wheel bearing,
front, inner -
Additional information: Wheel bearing,
front, inner
- Fitting Position: Front Axle
- Inner Diameter [mm]: 22
- Outer Diameter [mm]: 45.25
- Height [mm]: 17
- Bearing Type: Tapered Roller Bearing
- Name: RATTALAAGER
- Manufacturer: MEY
Alternative Repair Kit: 014 033 0092, 100 098 0029/S, 014 033 0097, 014 033 0100
- Fitting Position: Front Axle
- Supplementary Article/Info 2: with shaft seal
- Width 1 [mm]: 15.5
- Width 2 [mm]: 17.5
- Outer Diameter 1 [mm]: 45.2
- Outer Diameter 2 [mm]: 68
- Inner Diameter 1 [mm]: 22
- Inner Diameter 2 [mm]: 41
- Manufacturer: DENCKERMANN ZAWIESZENIE
- Lisainfo: W413027 DKM
- Additional information: W413027 DKM
- Fitting Position: Front Axle
-
Outer Diameter [mm]: 68,
45 -
Inner Diameter [mm]: 41,
22 -
Width [mm]: 18,
17 - Manufacturer: METZGER
- Lisainfo: WM 521 METZGER
- Additional information: WM 521 METZGER
-
Vehicle Identification Number (VIN) from: 24-
E- 023828 -
Fitting Position: Front Axle Left,
Front Axle Right - Quantity per axle: 2
- Outer Diameter 1 [mm]: 68
- Inner Diameter 1 [mm]: 41
- Width 1 [mm]: 18
- Outer Diameter 2 [mm]: 45
- Inner Diameter 2 [mm]: 22
- Width 2 [mm]: 17
-
Supplementary Article/Info 2: with nut,
with shaft seal - Full Set:
- Manufacturer: TOPRAN
General Information: Any and all spare parts we supply are solely intended for the designated purpose as defined by us. Installation by trained personnel only. Our products are usually supplied without assembly instructions. Installation in vehicles other than those specified by us may lead to the exclusion of warranty.
- Fitting Position: Front Axle
- Width [mm]: 18
- Inner Diameter [mm]: 22
- Outer Diameter 1 [mm]: 67.98
- Manufacturer: METELLI LOZYSKA KOLA PIASTY
-
Fitting Position: Rear Axle Left,
Rear Axle Right - Inner Diameter 1 [mm]: 35
- Inner Diameter 2 [mm]: 35
- Outer Diameter 1 [mm]: 62
- Width 1 [mm]: 17
- Width 2 [mm]: 19
- Outer Diameter 2 [mm]: 72
- Weight [kg]: 0.38
- Manufacturer: A.B.S.
- Fitting Position: Front Axle
- Width 1 [mm]: 15.5
- Width 2 [mm]: 17.5
- Outer Diameter 1 [mm]: 45.2
- Outer Diameter 2 [mm]: 68
- Inner Diameter 1 [mm]: 22
- Inner Diameter 2 [mm]: 41
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: MAX
- Bearing Type: Tapered Roller Bearing
-
Fitting Position: Front Axle Left,
Front Axle Right - Outer Diameter 1 [mm]: 68
- Width 1 [mm]: 17.5
- Inner Diameter 1 [mm]: 41
- Weight [kg]: 0.42
- Supplementary Article/Info 2: with shaft seal
- Manufacturer: FEBI BILSTEIN
General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
- Fitting Position: Front Axle
-
Vehicle Identification Number (VIN) from: 24-
E- 023828 - Width [mm]: 16.6
- Inner Diameter [mm]: 22
- Outer Diameter [mm]: 45.2
- Width 1 [mm]: 15.5
- Width 2 [mm]: 17.5
- Outer Diameter 1 [mm]: 68
- Inner Diameter 1 [mm]: 41
- Manufacturer: OPTIMAL
- Fitting Position: Front Axle
-
Lisainfo: Wheel bearing kit,
for one front wheel -
Additional information: Wheel bearing kit,
for one front wheel
- Fitting Position: Front Axle
-
Supplementary Article/Supplementary Info: with fastening/
mounting material - Inner Diameter 1 [mm]: 22
- Inner Diameter 2 [mm]: 41
- Outer Diameter 1 [mm]: 45.24
- Outer Diameter 2 [mm]: 68
- Height 1 [mm]: 17
- Height 2 [mm]: 18.5
- Bearing Type: Tapered Roller Bearing
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: MEY
-
Lisainfo: 1000980029/
S -
Additional information: 1000980029/
S
General Information: With mounting materials, to fit most models. Please check fit accuracy before installation.
- Fitting Position: Rear Axle
- Width 1 [mm]: 19
- Width 2 [mm]: 17
- Outer Diameter 1 [mm]: 62
- Outer Diameter 2 [mm]: 72
- Inner Diameter 1 [mm]: 35
- Inner Diameter 2 [mm]: 35
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: MAX
- Fitting Position: Rear Axle
- Width [mm]: 19
- Inner Diameter [mm]: 35
- Outer Diameter [mm]: 62
- Width 2 [mm]: 17
- Inner Diameter 2 [mm]: 35
- Outer Diameter 2 [mm]: 72
- Net weight [kg]: 0.57
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: NK
- Height [mm]: 64
- Outer Diameter 1 [mm]: 62.02
- Inner Diameter 1 [mm]: 35
- Fitting Position: Rear Axle
- Inner Diameter 2 [mm]: 35
- Width 1 [mm]: 19
- Width 2 [mm]: 17
- Outer Diameter 2 [mm]: 72
- Weight [kg]: 0.606
- Manufacturer: VAICO
General Information: In the warranty, we always make a distinction between wear parts and vehicle parts. All wear parts are subject to a reduced warranty period and a maximum mileage. Brake components such as brake disks, brake pads, etc. maximum of 1000 km (break-in period). Therefore, warranty claims for brake parts are only reviewed with an installation invoice and a record of the wheel hub run-out measurement, including photos. For brake disks and brake pads, the break-in requirements specified by the vehicle manufacturer must be observed. When replacing brakes, the chassis components must always be checked with regard to clearance and the wheel hub with regard to wobble, and the appropriate documentation must be produced. If the vehicle is no longer in its original condition due to tuning work such as wheel accessories and tracking plates, the entitlement to make warranty claims is lost due to third-party work. The same warranty claims are lost if the vehicle is used for motor sports or similar events.
- Fitting Position: Rear Axle
- Required quantity: 2
- Manufacturer: DRIVE
- Outer Diameter 1 [mm]: 45
- Width 1 [mm]: 15
- Inner Diameter 1 [mm]: 21
-
Fitting Position: Front Axle Right,
Front Axle Left - Manufacturer: SNR
- Name: SN R154.24
- Fitting Position: Front Axle
- Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
- Inner Diameter 1 [mm]: 22
- Outer Diameter 1 [mm]: 45.2
- Width 1 [mm]: 16.6
- Inner Diameter 2 [mm]: 41
- Outer Diameter 2 [mm]: 68
- Width 2 [mm]: 18
- SVHC: No SVHC present!
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: FAG
- Fitting Position: Front Axle
- Required quantity: 2
- Width 1 [mm]: 15.5
- Width 2 [mm]: 17.5
- Supplementary Article/Info 2: with shaft seal
- Outer Diameter 1 [mm]: 45.2
- Outer Diameter 2 [mm]: 68
- Inner Diameter 1 [mm]: 22
- Inner Diameter 2 [mm]: 41
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: SKF
- Width [mm]: 19
- Inner Diameter [mm]: 35
- Outer Diameter [mm]: 62
- Bearing Type: Rolling Bearing
-
Fitting Position: Rear Axle Left,
Rear Axle Right - Weight [kg]: 0.212
- Manufacturer: FEBI
General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
- Fitting Position: Rear Axle
- Width 1 [mm]: 19
- Width 2 [mm]: 17
- Outer Diameter 1 [mm]: 62
- Outer Diameter 2 [mm]: 72
- Inner Diameter 1 [mm]: 35
- Inner Diameter 2 [mm]: 35
- Manufacturer: OPTIMAL
- Width [mm]: 17
- Inner Diameter [mm]: 35
- Outer Diameter [mm]: 72
- Bearing Type: Cylindrical Roller Bearing
-
Fitting Position: Rear Axle Left,
Rear Axle Right - Outer Diameter 1 [mm]: 62
- Width 1 [mm]: 18.2
- Inner Diameter 1 [mm]: 35
- Weight [kg]: 0.58
-
Supplementary Article/Supplementary Info: with fastening/
mounting material - Manufacturer: FEBI BILSTEIN
General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
- Fitting Position: Rear Axle
- Supplementary Article/Supplementary Info: Photo corresponds to scope of supply
- Outer Diameter 1 [mm]: 72
- Width 1 [mm]: 17
- Outer Diameter 2 [mm]: 62
- Width 2 [mm]: 19
- Inner Diameter [mm]: 35
- SVHC: No SVHC present!
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: FAG
- Outer Diameter 1 [mm]: 62
- Width 1 [mm]: 18
-
Fitting Position: Rear Axle Right,
Rear Axle Left - Manufacturer: SNR
- Name: SN R154.08
- Fitting Position: Rear Axle
- Required quantity: 2
- Width 1 [mm]: 19
- Width 2 [mm]: 17
- Outer Diameter 1 [mm]: 62
- Outer Diameter 2 [mm]: 72
- Inner Diameter 1 [mm]: 35
- Inner Diameter 2 [mm]: 35
- Name: RATTALAAGRIKOMPLEKT
- Manufacturer: SKF
