• Rim Size [inch]: 16.0
• Fitting Position: Rear Axle
• Brake Disc Type: solid
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Number of Holes: 5
• Surface: Coated

• Rim Size [inch]: 17.0
• Fitting Position: Rear Axle
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Number of Holes: 5
• Surface: Coated

• Rim Size [inch]: 19.0
• Fitting Position: Front Axle
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Number of Holes: 5
• Surface: Coated

• Fitting Position: Rear Axle
• Brake Disc Type: solid
• Brake Disc Thickness [mm]: 12
• Bolt Hole Circle Ø [mm]: 108
• Number of Holes: 5
• Supplementary Article/Info 2: with bolts/screws
• Height [mm]: 43
• Machining: High-carbon
• Centering Diameter [mm]: 63
• Surface: Coated
• Outer Diameter [mm]: 302
• Manufacturer: KAMOKA

• Brake Size: 16"
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Brake Disc Type: solid
• Fitting Position: Rear Axle
• Height [mm]: 43
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Supplementary Article/Info 2: without wheel hub, without wheel studs
• Number of Holes: 5
• Minimum thickness [mm]: 9.5
• Name: Piduriketas
• Manufacturer: MAX

• Fitting Position: Rear Axle
• Brake Disc Type: Vented
• Brake Disc Thickness [mm]: 20
• Bolt Hole Circle Ø [mm]: 108
• Number of Holes: 5
• Height [mm]: 43
• Centering Diameter [mm]: 63
• Surface: Coated
• Outer Diameter [mm]: 320
• Manufacturer: KAMOKA
• Lisainfo: 103558
• Additional information: 103558

• Fitting Position: Rear Axle
• Brake Size: 16"
• Quantity per packing unit: 2
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Minimum thickness [mm]: 9.5
• Height [mm]: 43
• Rim Hole Number: 5
• Brake Disc Type: solid
• Centering Diameter [mm]: 64
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Hub Diameter [mm]: 153
• Weight [kg]: 5.18
• Installation Information: Important: Observe Fitting Instructions
• Manufacturer: A.B.S.

• Engine Code: B 4204 T28
• Brake Disc Thickness [mm]: 12
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 42.8
• Outer Diameter [mm]: 302
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: solid
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 9.5
• Centering Diameter [mm]: 63
• Weight [kg]: 5.4
• Observe service information:
• Manufacturer: FEBI BILSTEIN
• Lisainfo: 172979 FEBI
• Additional information: 172979 FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Engine Code: B 4204 T28
• Brake Disc Thickness [mm]: 12
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 43
• Outer Diameter [mm]: 302
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: solid
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 9.5
• Centering Diameter [mm]: 63
• Weight [kg]: 5.4
• Observe service information:
• Manufacturer: BLUEPRINT

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Engine Code: B 4204 T28
• Brake Disc Thickness [mm]: 12
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 42.8
• Outer Diameter [mm]: 302
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: solid
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 9.5
• Centering Diameter [mm]: 63
• Weight [kg]: 5.4
• Name: SW 33 10 6471
• Manufacturer: SWAG

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Rim Size [inch]: 17.0
• Fitting Position: Front Axle
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Number of Holes: 5
• Surface: Coated

• Fitting Position: Rear Axle
• Rim Size [inch]: 17
• Quantity per packing unit: 2
• Brake Disc Type: Vented
• Number of Holes: 5
• Test Mark: E4 90R-02C0703/2627
• Surface: Coated
• Machining: High-carbon
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Minimum thickness [mm]: 17.5
• Centering Diameter [mm]: 63.6
• Height [mm]: 43
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE BG4978C
• Quality class: PJ

• Brake Disc Thickness [mm]: 20
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 43
• Outer Diameter [mm]: 320
• Bolt Hole Circle Ø [mm]: 108
• Machining: High-carbon
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 17.5
• Centering Diameter [mm]: 63
• Weight [kg]: 7
• Observe service information:
• Manufacturer: FEBI BILSTEIN
• Quantity per packing unit: 2
• Lisainfo: 171444 FEBI
• Additional information: 171444 FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Brake Size: 17"
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Brake Disc Type: internally vented
• Fitting Position: Front Axle
• Height [mm]: 48
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.5
• Supplementary Article/Info 2: without wheel hub, without wheel studs
• Number of Holes: 5
• Minimum thickness [mm]: 25.5
• Name: Piduriketas
• Manufacturer: MAX

• Fitting Position: Rear Axle
• Braking System: for vehicles with Performance brakes
• Brake Size: 17"
• Quantity per packing unit: 2
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Minimum thickness [mm]: 17.5
• Height [mm]: 43
• Rim Hole Number: 5
• Brake Disc Type: Vented
• Centering Diameter [mm]: 64
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Hub Diameter [mm]: 153
• Weight [kg]: 7.14
• Installation Information: Important: Observe Fitting Instructions
• Manufacturer: A.B.S.

• Brake Disc Thickness [mm]: 20
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 43
• Outer Diameter [mm]: 320
• Bolt Hole Circle Ø [mm]: 108
• Machining: High-carbon
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 17.5
• Centering Diameter [mm]: 63
• Weight [kg]: 7
• Observe service information:
• Name: Piduriketas
• Manufacturer: BLP
• Lisainfo: ADBP430016 BLUEPRINT
• Additional information: ADBP430016 BLUEPRINT

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle
• Rim Size [inch]: 16
• Quantity per packing unit: 2
• Brake Disc Type: Vented
• Number of Holes: 5
• Test Mark: E4 90R-02C0703/2622
• Surface: Coated
• Machining: High-carbon
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Minimum thickness [mm]: 9.5
• Centering Diameter [mm]: 63.6
• Height [mm]: 43
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE BG4950C
• Quality class: PJ

• Fitting Position: Rear Axle
• Brake Size: 16"
• Brake Disc Type: solid
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Height [mm]: 43
• Minimum thickness [mm]: 9.5
• Machining: High-carbon
• Surface: Coated
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Hole Arrangement/Number: 05/06
• Supplementary Article/Info 2: without wheel hub, without wheel studs
• Weight [kg]: 5.2
• Assy./disassy. by qualified personnel required!:
• Name: HE 8DD355126991
• Manufacturer: HELLA PAGID

• Brake Size: 17"
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Brake Disc Type: Vented
• Fitting Position: Rear Axle
• Minimum thickness [mm]: 17.5
• Surface: painted
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 43
• Centering Diameter [mm]: 63.5
• Name: Piduriketas
• Manufacturer: QUARO

• Rim Size [inch]: 18.0
• Fitting Position: Front Axle
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Number of Holes: 5
• Surface: Coated

• Fitting Position: Front Axle
• Brake Disc Type: Vented
• Brake Disc Thickness [mm]: 28
• Bolt Hole Circle Ø [mm]: 108
• Number of Holes: 5
• Supplementary Article/Info 2: with bolts/screws
• Height [mm]: 48
• Machining: High-carbon
• Centering Diameter [mm]: 63
• Surface: Coated
• Outer Diameter [mm]: 322
• Manufacturer: KAMOKA
• Quantity per packing unit: 2

• Fitting Position: Rear Axle
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Surface: Coated
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Height [mm]: 43
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 9.5
• Weight [kg]: 5.3
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Rear Axle
• Rim Size [inch]: 16
• Brake Size: 16"
• for model code: RK01
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Brake Disc Thickness [mm]: 12
• Number of Holes: 5
• Height [mm]: 43
• Centering Diameter [mm]: 64
• Outer Diameter [mm]: 302
• Machining: High-carbon
• Surface: Coated
• Minimum thickness [mm]: 9.5
• Manufacturer: BREMBO
• Name: BR 08.D249.11

• Brake Disc Thickness [mm]: 28
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 48
• Outer Diameter [mm]: 322
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Front Axle
• Minimum thickness [mm]: 25
• Centering Diameter [mm]: 63.6
• Weight [kg]: 10
• Observe service information:
• Manufacturer: FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Front Axle
• Rim Size [inch]: 17
• Model Year from: 2020
• Equipment Code: RC01
• Brake Disc Type: Vented
• Number of Holes: 5
• Test Mark: E1 90R-02C0277/1785
• Surface: Coated
• Machining: High-carbon
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Minimum thickness [mm]: 25.5
• Centering Diameter [mm]: 63.5
• Height [mm]: 48
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Quantity per packing unit: 2

• Fitting Position: Rear Axle
• Rim Size [inch]: 17
• Braking System: for vehicles with Performance brakes
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented
• Brake Disc Thickness [mm]: 20
• Number of Holes: 5
• Height [mm]: 43
• Centering Diameter [mm]: 64
• Outer Diameter [mm]: 320
• Surface: Coated
• Minimum thickness [mm]: 17.5
• Manufacturer: BREMBO
• Name: BR 09.C938.11
• Quality class: Q

• Rim Size [inch]: 18
• Fitting Position: Front Axle
• Brake Disc Type: Vented
• Surface: Coated
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Centering Diameter [mm]: 63.6
• Height [mm]: 48
• Minimum thickness [mm]: 27.5
• Rim Hole Number: 5
• Number of mounting bores: 1
• Test Mark: ECE-R90
• Weight [kg]: 12.06
• Manufacturer: VALEO

Supplementary Article/Info 2: without bolts/screws, without integrated wheel bearing

• Brake Disc Thickness [mm]: 28
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 48
• Outer Diameter [mm]: 322
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Front Axle
• Minimum thickness [mm]: 25
• Centering Diameter [mm]: 63.6
• Weight [kg]: 10
• Observe service information:
• Name: Piduriketas
• Manufacturer: BLP
• Quantity per packing unit: 2

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Engine Code: B 4204 T28
• Fitting Position: Rear Axle
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Minimum thickness [mm]: 9.5
• Height [mm]: 43
• Bolt Hole Circle Ø [mm]: 108
• Brake Disc Type: solid
• Centering Diameter [mm]: 63.6
• Number of Holes: 5
• Surface: Coated
• Machining: High-carbon
• fulfils ECE norm: ECE-R90
• Bore Diameter up to [mm]: 15.8
• Name: Piduriketas
• Manufacturer: BOS
• Quantity per packing unit: 2

• Fitting Position: Front Axle
• Brake Size: 17"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Height [mm]: 48
• Minimum thickness [mm]: 25.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.5
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Packaging length [cm]: 34.3
• Packaging width [cm]: 34.3
• Packaging height [cm]: 7.5
• Weight [kg]: 9.8
• Name: PIDURIKETAS
• Manufacturer: TEX
• Quantity per packing unit: 2

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Front Axle
• Brake Disc Type: Vented
• Brake Disc Thickness [mm]: 30
• Bolt Hole Circle Ø [mm]: 108
• Number of Holes: 5
• Height [mm]: 41
• Centering Diameter [mm]: 63
• Surface: Coated
• Outer Diameter [mm]: 345
• Manufacturer: KAMOKA
• Quantity per packing unit: 2

• Fitting Position: Rear Axle
• Brake Size: 16"
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Minimum thickness [mm]: 9.5
• Number of Holes: 5
• Thread Size: 15,6
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 43
• Centering Diameter [mm]: 63.5
• Colour: black
• Surface: painted
• Machining: High-carbon
• Test Mark: E1 90R-02 C0190/0599
• Name: Piduriketas
• Manufacturer: TRW

SVHC: No information available, please contact the manufacturer!

• Fitting Position: Rear Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented
• Surface: Coated
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Height [mm]: 43
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 17.5
• Weight [kg]: 7
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 19"
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Brake Disc Type: Vented
• Machining: High-carbon
• Surface: Coated
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 48
• Centering Diameter [mm]: 63.5
• Supplementary Article/Info 2: with bolts/screws
• Test Mark: E1 90R-02C0115/0861
• Rim Hole Number: 5
• Name: Piduriketas
• Manufacturer: QUARO

• Fitting Position: Rear Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Minimum thickness [mm]: 17.5
• Brake Disc Type: Vented
• Surface: Coated
• Number of Holes: 5
• Supplementary Article/Info 2: with bolts/screws
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 43
• Centering Diameter [mm]: 63.5
• Inner Diameter [mm]: 141
• Bore Diameter [mm]: 15.8
• Test Mark: E1 90R-02C0115/1185
• MAPP code available:
• Name: Piduriketas
• Manufacturer: ATE
• Quality class: Q

• Fitting Position: Front Axle
• Equipment Code: RC02
• Model Year from: 2020
• Brake Size: 17"
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Minimum thickness [mm]: 25.5
• Brake Disc Type: Vented
• Machining: High-carbon
• Surface: Coated
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 48
• Centering Diameter [mm]: 63.5
• Inner Diameter [mm]: 141
• Bore Diameter [mm]: 15.8
• Supplementary Article/Info 2: with bolts/screws
• MAPP code available:
• Test Mark: E1 90R-02C0115/0201
• Name: Piduriketas
• Manufacturer: ATE
• Quantity per packing unit: 2
• Quality class: Q

• Engine Code: B 4204 T28
• Brake Disc Thickness [mm]: 30
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 48
• Outer Diameter [mm]: 366
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Front Axle
• Minimum thickness [mm]: 27.5
• Centering Diameter [mm]: 63
• Weight [kg]: 13.1
• Observe service information:
• Manufacturer: FEBI

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Rear Axle
• Brake Size: 16"
• Quantity per packing unit: 2
• Brake Disc Type: solid
• Outer Diameter [mm]: 302
• Brake Disc Thickness [mm]: 12
• Height [mm]: 43
• Minimum thickness [mm]: 9.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Packaging length [cm]: 32.8
• Packaging width [cm]: 32.8
• Packaging height [cm]: 10.5
• Weight [kg]: 5.2
• Name: Piduriketas
• Manufacturer: TEX

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Front Axle
• Rim Size [inch]: 18
• Brake Disc Type: Vented
• Number of Holes: 5
• Test Mark: E1 90R-02C0277/1387
• Surface: Coated
• Machining: High-carbon
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Centering Diameter [mm]: 63.6
• Height [mm]: 48
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE BG9231C
• Quantity per packing unit: 2
• Quality class: PJ

• Fitting Position: Rear Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Height [mm]: 43
• Minimum thickness [mm]: 17.5
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Packaging length [cm]: 32.8
• Packaging width [cm]: 32.8
• Packaging height [cm]: 10.5
• Weight [kg]: 7
• Manufacturer: TEX

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs Name: TARCZA HAM. VOLVO T. S60/S90/V60/V90/XC60/XC90 2,0 14-

• Fitting Position: Front Axle
• Rim Size [inch]: 17
• Brake Size: 17"
• Brake Disc Type: internally vented
• Brake Disc Thickness [mm]: 28
• Number of Holes: 5
• Height [mm]: 47
• Centering Diameter [mm]: 64
• Outer Diameter [mm]: 322
• Machining: High-carbon
• Surface: Coated
• Minimum thickness [mm]: 25.5
• Name: BR 09.D251.11
• Manufacturer: BREMBO
• Quantity per packing unit: 2

• Fitting Position: Front Axle
• Brake Size: 18"
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Brake Disc Type: internally vented
• Minimum thickness [mm]: 27.5
• Height [mm]: 48
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.5
• Supplementary Article/Info 2: without wheel hub, without wheel studs
• Surface: painted
• Machining: High-carbon
• Number of Holes: 5
• Name: Piduriketas
• Manufacturer: QUARO

• Engine Code: B 4204 T28
• Brake Disc Thickness [mm]: 30
• Rim Hole Number: 5
• Number of mounting bores: 1
• Thickness [mm]: 48
• Outer Diameter [mm]: 366
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Brake Disc Type: internally vented
• Fitting Position: Front Axle
• Minimum thickness [mm]: 27.5
• Centering Diameter [mm]: 63
• Weight [kg]: 13.1
• Observe service information:
• Manufacturer: BLUE PRINT
• Quantity per packing unit: 2

General Information: These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.

• Fitting Position: Front Axle
• Rim Size [inch]: 19
• Brake Disc Type: Vented
• Number of Holes: 5
• Test Mark: E1 90R-02C0343/2176
• Surface: Coated
• Machining: High-carbon
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Centering Diameter [mm]: 63.6
• Height [mm]: 48
• Manufacturer: DELPHI LOCKHEED HAMULCE
• Name: DE BG9233C
• Quantity per packing unit: 2
• Quality class: PJ

• Fitting Position: Front Axle
• Brake Size: 19"
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Height [mm]: 48.1
• Rim Hole Number: 5
• Brake Disc Type: Vented
• Centering Diameter [mm]: 64
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Hub Diameter [mm]: 153
• Weight [kg]: 13.02
• Installation Information: Important: Observe Fitting Instructions
• Manufacturer: A.B.S.

• Fitting Position: Front Axle
• Rim Size [inch]: 18
• Brake Size: 18"
• Brake Disc Type: internally vented
• Brake Disc Thickness [mm]: 30
• Number of Holes: 5
• Height [mm]: 48
• Centering Diameter [mm]: 64
• Outer Diameter [mm]: 345
• Machining: High-carbon
• Surface: Coated
• Minimum thickness [mm]: 27.5
• Manufacturer: BREMBO
• Name: BR 09.C936.11
• Quality class: Q

• Fitting Position: Front Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented
• Surface: Coated
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 25.5
• Weight [kg]: 9.8
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 18"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Number of Holes: 5
• Thread Size: 15,8
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 48
• Centering Diameter [mm]: 63.6
• Colour: black
• Surface: painted
• Test Mark: E1 90R-02 C0176/0633
• Name: Piduriketas
• Manufacturer: TRW
• Additional information: DF6939S TRW
• Lisainfo: DF6939S TRW

SVHC: No information available, please contact the manufacturer!

• Engine Code: B 4204 T28
• Fitting Position: Front Axle
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Minimum thickness [mm]: 25.5
• Height [mm]: 48
• Bolt Hole Circle Ø [mm]: 108
• Brake Disc Type: Vented
• Centering Diameter [mm]: 63.5
• Number of Holes: 5
• Surface: Coated
• Machining: High-carbon
• fulfils ECE norm: ECE-R90
• Bore Diameter up to [mm]: 15.8
• Name: Piduriketas
• Manufacturer: BOS

• Fitting Position: Front Axle
• Brake Size: 18"
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Height [mm]: 48
• Rim Hole Number: 5
• Brake Disc Type: Vented
• Centering Diameter [mm]: 64
• Bolt Hole Circle Ø [mm]: 108
• Surface: Coated
• Material: Grey Cast Iron
• Hub Diameter [mm]: 153
• Weight [kg]: 12
• Installation Information: Important: Observe Fitting Instructions
• Manufacturer: A.B.S.

• Fitting Position: Front Axle
• Rim Size [inch]: 19
• Brake Size: 19"
• Brake Disc Type: internally vented
• Brake Disc Thickness [mm]: 30
• Number of Holes: 5
• Height [mm]: 48
• Centering Diameter [mm]: 64
• Outer Diameter [mm]: 366
• Machining: High-carbon
• Surface: Coated
• Minimum thickness [mm]: 27.5
• Manufacturer: BREMBO
• Name: BR 09.C937.11
• Quantity per packing unit: 2

Brief Information: PVT vented disc. The PVT disc uses, in its ventilation chamber, pillars instead of vanes. Disc cooling capacity is enhanced by an extra 40% and therefore provides more resistance against thermal cracking.

• Fitting Position: Front Axle
• Brake Size: 17"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Height [mm]: 48
• Minimum thickness [mm]: 25.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.5
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Weight [kg]: 9.8
• Assy./disassy. by qualified personnel required!:
• Name: HE 8DD355125471
• Manufacturer: HELLA PAGID

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Front Axle
• Brake Size: 19"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Minimum thickness [mm]: 27.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Weight [kg]: 13.1
• Assy./disassy. by qualified personnel required!:
• Name: HE 8DD355132411
• Manufacturer: HELLA PAGID

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Front Axle
• Brake Size: 19"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Minimum thickness [mm]: 27.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.6
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Packaging length [cm]: 39.8
• Packaging width [cm]: 39.8
• Packaging height [cm]: 9.5
• Weight [kg]: 13.1
• Manufacturer: TEXTAR TARCZE HAMULCOWE
• Quantity per packing unit: 2

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Front Axle
• Quantity per packing unit: 2
• Brake Disc Type: Vented
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Supplementary Article/Info 2: without bolts/screws
• Height [mm]: 48
• Number of Holes: 5
• Quantity Unit: Set
• Surface: Coated
• Version: JC
• Bore Diameter [mm]: 63.5
• Minimum thickness [mm]: 25.5
• Packing Type: Carton
• Packaging length [cm]: 34.1
• Packaging width [cm]: 34.1
• Packaging height [cm]: 12.7
• Manufacturer: JURID

• Fitting Position: Front Axle
• Brake Size: 19"
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Brake Disc Type: Vented
• Machining: High-carbon
• Surface: Coated
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 48
• Centering Diameter [mm]: 63.5
• Inner Diameter [mm]: 141
• Bore Diameter [mm]: 15.8
• Supplementary Article/Info 2: with bolts/screws
• MAPP code available:
• Test Mark: E1 90R-02C0115/0861
• Name: Piduriketas
• Manufacturer: ATE
• Quality class: Q

• Fitting Position: Front Axle
• Brake Size: 18"
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Minimum thickness [mm]: 27.5
• Brake Disc Type: Vented
• Machining: High-carbon
• Surface: Coated
• Number of Holes: 5
• Bolt Hole Circle Ø [mm]: 108
• Height [mm]: 48
• Centering Diameter [mm]: 63.5
• Inner Diameter [mm]: 141
• Bore Diameter [mm]: 15.8
• Supplementary Article/Info 2: with bolts/screws
• MAPP code available:
• Test Mark: E1 90R-02C0115/1009
• Name: Piduriketas
• Manufacturer: ATE
• Quality class: Q

• Fitting Position: Front Axle
• Brake Size: 18"
• Brake Disc Type: internally vented
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Minimum thickness [mm]: 27.5
• Machining: High-carbon
• Surface: Coated
• Inner Diameter [mm]: 141
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 63.5
• Hole Arrangement/Number: 05/06
• Wheel Bolt Bore Diameter [mm]: 15.8
• Packaging length [cm]: 36.8
• Packaging width [cm]: 36.8
• Packaging height [cm]: 7
• Weight [kg]: 11.9
• Name: PIDURIKETAS
• Manufacturer: TEX

Supplementary Article/Info 2: without wheel hub, without wheel bearing, without wheel studs

• Fitting Position: Rear Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented, Perforated
• Surface: Coated
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Height [mm]: 43
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 17.5
• Weight [kg]: 6.9
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 18"
• Brake Disc Type: internally vented
• Surface: Coated
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 27.5
• Weight [kg]: 12.3
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 19"
• Brake Disc Type: internally vented
• Surface: Coated
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 27.5
• Weight [kg]: 13
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Rear Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented, slotted
• Surface: Coated
• Outer Diameter [mm]: 320
• Brake Disc Thickness [mm]: 20
• Height [mm]: 43
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• directional:
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 17.5
• Weight [kg]: 6.9
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 17"
• Quantity per packing unit: 2
• Brake Disc Type: internally vented, slotted
• Surface: Coated
• Outer Diameter [mm]: 322
• Brake Disc Thickness [mm]: 28
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• directional:
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 25.5
• Weight [kg]: 9.7
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 18"
• Brake Disc Type: internally vented, Perforated
• Surface: Coated
• Outer Diameter [mm]: 345
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ECE R90 APPROVED
• Minimum thickness [mm]: 27.5
• Weight [kg]: 12.3
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Brake Size: 19"
• Brake Disc Type: internally vented, Perforated
• Surface: Coated
• Outer Diameter [mm]: 366
• Brake Disc Thickness [mm]: 30
• Height [mm]: 48
• Rim Hole Number: 5
• Bolt Hole Circle Ø [mm]: 108
• Centering Diameter [mm]: 64
• Test Mark: ohne ABE
• Minimum thickness [mm]: 27.5
• Weight [kg]: 13
• Hole Arrangement/Number: 6/5
• Manufacturer: ZIMMERMANN

• Fitting Position: Front Axle
• Rim Size [inch]: 18
• Brake Size: 18"
• Brake Disc Type: perforated/vented
• Brake Disc Thickness [mm]: 30
• Number of Holes: 5
• Height [mm]: 48
• Centering Diameter [mm]: 63.6
• Outer Diameter [mm]: 345
• Machining: High-carbon
• Surface: Coated
• Minimum thickness [mm]: 28.1
• Manufacturer: BREMBO
• Quantity per packing unit: 2

General Information: The specific drilling of Brembo Xtra brake discs provides a brilliant and efficient performance in any braking condition, to emphasise the driving style of true enthusiasts.
